# Agent Workflows import { Callout } from 'fumadocs-ui/components/callout'; import { Card, Cards } from 'fumadocs-ui/components/card'; import { Step, Steps } from 'fumadocs-ui/components/steps'; Walk through complete agent workflows — from the user's prompt to the final result. Each example shows every step the agent takes, the API calls it makes, and the data it works with. Example 1: Bridge USDC Across Chains [#example-1-bridge-usdc-across-chains] **User prompt:** ``` Bridge 100 USDC from Arbitrum to Base ``` Discover supported chains [#discover-supported-chains] The agent calls the chains endpoint to confirm Arbitrum and Base are supported and to get their chain IDs. ```bash GET https://app.across.to/api/swap/chains ``` The agent finds: * **Arbitrum** — chain ID `42161` * **Base** — chain ID `8453` Look up token addresses [#look-up-token-addresses] The agent fetches the token list for both chains to find the USDC contract addresses. ```bash GET https://app.across.to/api/swap/tokens?chainId=42161 GET https://app.across.to/api/swap/tokens?chainId=8453 ``` The agent finds: * USDC on Arbitrum: `0xaf88d065e77c8cC2239327C5EDb3A432268e5831` (6 decimals) * USDC on Base: `0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913` (6 decimals) Get a quote [#get-a-quote] The agent formats the amount (100 USDC = `100000000` with 6 decimals) and requests a quote. ```bash GET https://app.across.to/api/swap/approval ?originChainId=42161 &destinationChainId=8453 &inputToken=0xaf88d065e77c8cC2239327C5EDb3A432268e5831 &outputToken=0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913 &amount=100000000 &depositor=0xUserWallet &tradeType=minOutput ``` The response includes: * `expectedFillTime`: **2 seconds** * `simulationSuccess`: **true** * `approvalTxns`: 1 approval needed (first time only) * `swapTx`: the bridge transaction calldata Execute token approval [#execute-token-approval] The quote includes an approval transaction because this is the first time bridging USDC through this SpokePool. The agent sends it. ``` Transaction: Approve SpokePool to spend USDC Hash: 0xabc123... Status: Confirmed ``` On subsequent bridges, this step is skipped — the approval persists. Execute the bridge [#execute-the-bridge] The agent sends the main swap transaction using the calldata from the quote. ``` Transaction: Deposit 100 USDC into Arbitrum SpokePool Hash: 0xdef456... Status: Confirmed in block 284719304 ``` The agent reports back: > Bridged 100 USDC from Arbitrum to Base. Expected fill time: \~2 seconds. > Tx: [https://arbiscan.io/tx/0xdef456](https://arbiscan.io/tx/0xdef456)... Track the deposit [#track-the-deposit] The agent polls the status endpoint until the deposit is filled. ```bash GET https://app.across.to/api/deposit/status ?originChainId=42161 &depositTxHash=0xdef456... ``` After \~2 seconds: ```json { "status": "filled", "fillTxHash": "0x789abc...", "destinationChainId": 8453 } ``` The agent confirms: **Transfer complete.** 100 USDC arrived on Base. **Try it yourself.** Give your agent this prompt: ``` Bridge 100 USDC from Arbitrum to Base ``` With the [Across skill installed](/ai-agents), the agent handles the entire flow autonomously. *** Example 2: Bridge + DeFi Deposit [#example-2-bridge--defi-deposit] **User prompt:** ``` Bridge 100 USDC from Arbitrum to Ethereum, swap to ETH, and deposit into Aave ``` Discover chains and tokens [#discover-chains-and-tokens] The agent resolves chain IDs and token addresses, same as Example 1. * **Arbitrum** (42161) — USDC: `0xaf88d065e77c8cC2239327C5EDb3A432268e5831` * **Ethereum** (1) — WETH: `0xC02aaA39b223FE8D0A0e5C4F27eAD9083C756Cc2` The agent identifies this as a cross-token bridge (USDC to WETH) with an embedded action. Build the embedded action [#build-the-embedded-action] The agent constructs an Aave deposit action targeting the WETH Gateway on Ethereum. ```json title="embedded action" { "target": "0x893411580e590D62dDBca8a703d61Cc4A8c7b2b9", "functionSignature": "function depositETH(address, address onBehalfOf, uint16 referralCode)", "args": [ { "value": "0x0000000000000000000000000000000000000000", "populateDynamically": false }, { "value": "0xUserWallet", "populateDynamically": false }, { "value": "0", "populateDynamically": false } ], "value": "0", "isNativeTransfer": false, "populateCallValueDynamically": true } ``` The key: `populateCallValueDynamically: true` tells the MulticallHandler to forward the entire ETH balance from the swap as `msg.value` to the Aave deposit. Get a quote with actions [#get-a-quote-with-actions] The agent uses `POST /swap/approval` with the actions array in the body and sets `recipient` to the MulticallHandler contract. ```bash POST https://app.across.to/api/swap/approval ?originChainId=42161 &destinationChainId=1 &inputToken=0xaf88d065e77c8cC2239327C5EDb3A432268e5831 &outputToken=0xC02aaA39b223FE8D0A0e5C4F27eAD9083C756Cc2 &amount=100000000 &depositor=0xUserWallet &recipient=0x924a9f036260DdD5808007E1AA95f08eD08aA569 &tradeType=exactInput Body: { "actions": [] } ``` The response confirms `simulationSuccess: true` — the full flow (bridge + swap + Aave deposit) has been simulated successfully. Execute approvals and bridge [#execute-approvals-and-bridge] The agent sends any required approval transactions, then the main swap transaction. ``` Transaction: Deposit USDC into Arbitrum SpokePool (with embedded Aave action) Hash: 0xfed987... Status: Confirmed ``` What happens next (handled by the protocol): 1. A relayer fills the intent on Ethereum, delivering ETH to the MulticallHandler 2. The MulticallHandler executes the Aave `depositETH()` call 3. Aave mints aWETH tokens to the user's address Confirm the result [#confirm-the-result] The agent tracks the deposit and confirms the full flow completed. > Bridge + Aave deposit complete. 100 USDC on Arbitrum has been converted to an aWETH lending position on Ethereum. > Deposit tx: [https://arbiscan.io/tx/0xfed987](https://arbiscan.io/tx/0xfed987)... > Expected fill: \~2 seconds. **Try it yourself.** Give your agent this prompt: ``` Bridge 100 USDC from Arbitrum to Ethereum, swap to ETH, and deposit into Aave ``` This uses [embedded crosschain actions](/introduction/embedded-actions) to compose bridge + DeFi in a single user transaction. *** More Resources [#more-resources] Full developer guide for the 5-step bridge flow used in Example 1. Complete code walkthrough for the bridge + Aave pattern in Example 2. More prompts organized by task category. # AGENTS.md import { Callout } from 'fumadocs-ui/components/callout'; import { Step, Steps } from 'fumadocs-ui/components/steps'; What is AGENTS.md [#what-is-agentsmd] [AGENTS.md](https://agents.md/) is a convention for providing project context to AI coding agents. When an agent like Claude Code, Codex, or Cursor opens your repository, it reads the nearest `AGENTS.md` (or `CLAUDE.md`, `.cursorrules`, etc.) to understand the project's architecture, conventions, and integration patterns. Why You Need One [#why-you-need-one] Without an `AGENTS.md`, coding agents have to guess how your Across integration works — which API endpoints you use, how you format amounts, where your bridge logic lives, and what security constraints to follow. With one, your agent can: * Call the correct Swap API endpoints without hallucinating URLs * Use your integrator ID and configured chains * Follow your project's conventions for error handling and token addresses * Avoid common mistakes like hardcoding addresses or logging private keys Drop this file in your project root as `AGENTS.md`, `CLAUDE.md`, or `.cursorrules` — whichever your agent framework reads. The content is the same. The Template [#the-template] Copy this template into your repository and fill in the placeholders: ````markdown title="AGENTS.md" # Project Context [YOUR PROJECT NAME] — [brief description of what the project does]. Built with [framework/stack]. Uses Across Protocol for crosschain token transfers. # Across Integration - **Integrator ID**: `0xYOUR_INTEGRATOR_ID` (2-byte hex, register at https://app.across.to) - **API Base URL**: `https://app.across.to/api` (production) - **Testnet API**: `https://testnet.across.to/api` (Sepolia testnet) - **Supported Chains**: [list the chains your app supports, e.g., Ethereum, Arbitrum, Base, Optimism] - **Supported Tokens**: [list tokens, e.g., USDC, USDT, WETH, ETH] - **SDK**: `@across-protocol/app-sdk` (if using the SDK) # Build & Test ```bash [your install command, e.g., pnpm install] [your build command, e.g., pnpm build] [your test command, e.g., pnpm test] [your dev command, e.g., pnpm dev] ``` # Key Files - `[path/to/bridge-logic]` — Main bridge integration (Swap API calls) - `[path/to/config]` — Chain and token configuration - `[path/to/hooks-or-utils]` — Bridge hooks/utilities - `[path/to/types]` — Type definitions for API responses # API Patterns All crosschain transfers go through the Swap API: 1. **Discover chains**: `GET /swap/chains` — returns supported chains with IDs 2. **Look up tokens**: `GET /swap/tokens?chainId={id}` — returns tokens for a chain 3. **Get a quote**: `GET /swap/approval?originChainId=...&destinationChainId=...&inputToken=...&outputToken=...&amount=...&depositor=...&tradeType=minOutput` 4. **Execute**: Send `approvalTxns` first (if any), then `swapTx` 5. **Track**: `GET /deposit/status?originChainId=...&depositTxHash=...` For embedded actions (bridge + DeFi in one tx): - Use `POST /swap/approval` with `actions` array in the body - Set `recipient` to the MulticallHandler contract address # Conventions - NEVER hardcode token addresses — always fetch from `/swap/tokens` - NEVER hardcode chain IDs in logic — use `/swap/chains` as source of truth - Format amounts using the token's `decimals` field (USDC = 6, WETH = 18) - Use `tradeType: "minOutput"` for standard bridges (user receives at least the specified amount) - Use `tradeType: "exactInput"` for embedded actions (exact input, variable output) - Always include the integrator ID in production API calls # Security - NEVER log or expose private keys, seed phrases, or signing keys - NEVER commit `.env` files or credentials - Always check `simulationSuccess` on the quote before executing transactions - Validate `checks.allowance` and `checks.balance` before sending - Use the API-provided gas estimates — don't hardcode gas limits - For embedded actions, verify the `recipient` is the MulticallHandler, not the user address # Common Agent Tasks When asked to: - **"Bridge tokens"** — Use the 5-step Swap API flow: chains → tokens → quote → approve → execute - **"Get a quote"** — Call `/swap/approval` with the route parameters - **"Check bridge status"** — Call `/deposit/status` with the origin chain ID and deposit tx hash - **"Add a new chain"** — Check `/swap/chains` to verify support, then add chain config - **"Bridge and deposit into DeFi"** — Use embedded actions with POST `/swap/approval` ```` Customization Guide [#customization-guide] Fill in Project Context [#fill-in-project-context] Replace the placeholders in the first section with your project name, description, and tech stack. Be specific — agents use this to understand the overall architecture. Configure Across Integration [#configure-across-integration] Add your integrator ID (required for production), the chains your app supports, and which tokens you bridge. If you only bridge USDC on Arbitrum and Base, say so — the agent won't try to use unsupported routes. Map Your Key Files [#map-your-key-files] Point the agent to where your bridge logic lives. Include the config file where chains/tokens are defined, the main integration file that calls the API, and any shared types or utilities. Add Project-Specific Conventions [#add-project-specific-conventions] If your project has additional rules (e.g., "always use BigInt for amounts", "wrap API calls in a try/catch with our logger"), add them to the Conventions section. The agent will follow these patterns in generated code. Define Common Tasks [#define-common-tasks] Add task-specific instructions for prompts your team uses frequently. For example, if you often ask the agent to "add a new bridge route", describe the exact files to modify and the pattern to follow. # AI Agents import { Callout } from 'fumadocs-ui/components/callout'; import { Card, Cards } from 'fumadocs-ui/components/card'; Add Across to your agent with one command [#add-across-to-your-agent-with-one-command] ```bash title="terminal" npx skills add https://github.com/across-protocol/skills --yes ``` Compatible with **Claude Code**, **Codex**, **Cursor**, **Openclaw**, and more. Connect to the Across MCP Server [#connect-to-the-across-mcp-server] ```text title="MCP Server URL" https://mcp.across.to/mcp ``` Add this URL to any MCP-compatible client — **Claude Desktop**, **Claude Code**, **Cursor**, **VS Code Copilot**, **Windsurf**, **Codex**. *** What your agent gets [#what-your-agent-gets] Once installed, your AI agent can: * **Bridge tokens** across 24+ chains with natural language commands * **Get live quotes** — fees, estimated fill times, and optimal routes * **Execute crosschain swaps** — USDC, USDT, WETH, and more * **Track deposits** — check fill status and confirmations in real time * **Compose embedded actions** — bridge + swap + deposit into DeFi in one transaction Supported Agents [#supported-agents] | Agent Framework | Status | | --------------- | --------- | | Claude Code | Supported | | Codex | Supported | | Cursor | Supported | | Openclaw | Supported | Two ways to connect [#two-ways-to-connect] | Approach | Best for | Setup | | --------------------------------------- | -------------------------------------------------------- | -------------------------------------------------------------------------------------------------- | | **Skills CLI** (`npx skills add`) | Claude Code, Codex, Cursor, Openclaw | One command — installs tool definitions directly into your agent config | | **[MCP Server](/ai-agents/mcp-server)** | Claude Desktop, Cursor, Windsurf, VS Code Copilot, Codex | Point your client at `https://mcp.across.to/mcp` — search docs, query chains, get live bridge fees | Use both together or pick whichever fits your workflow. Supported Chains [#supported-chains] Across currently supports **24+ mainnet chains** — including Ethereum, Arbitrum, Optimism, Base, Polygon, Unichain, and other major L2s. For the canonical list with contract addresses and explorer links, see the [Chains & Contracts](/chains-and-contracts) page. For the live machine-readable list, query the [`/swap/chains`](/api-reference/swap/chains/get) endpoint. How it works [#how-it-works] The skills package provides your agent with structured tool definitions that map directly to the Across Swap API. Your agent receives: 1. **Chain discovery** — query supported chains and tokens 2. **Quote generation** — get executable calldata for any crosschain transfer 3. **Transaction execution** — approval and bridge transaction helpers 4. **Status tracking** — monitor deposits until they're filled The agent handles the entire flow autonomously — from selecting the right route to executing the transaction. Example prompt [#example-prompt] Once the skill is installed, you can simply tell your agent: ``` Bridge 100 USDC from Arbitrum to Base ``` The agent will discover chains, look up token addresses, fetch a quote, handle approvals, and execute the bridge — all without any additional code. *** Explore [#explore] Search docs, query chains, and get live bridge fees from any MCP-compatible client. Hosted at mcp.across.to. Feed Across documentation to agents and RAG pipelines via llms.txt endpoints. Drop-in AGENTS.md for repos integrating Across — gives coding agents full context. Curated prompts for discovery, quoting, execution, tracking, and DeFi composition. End-to-end examples showing real agent sessions performing crosschain tasks. # Machine-Readable Docs import { Callout } from 'fumadocs-ui/components/callout'; import { Tabs, Tab } from 'fumadocs-ui/components/tabs'; Every page on this site is available in machine-readable markdown format. AI agents, RAG pipelines, and LLM tools can consume Across documentation without scraping HTML. Endpoints [#endpoints] | Endpoint | Content | Best For | | ------------------ | ---------------------------------------------- | ---------------------------------------------- | | `/llms.txt` | Page index with titles, URLs, and descriptions | Directory lookup — find the right page to read | | `/llms-full.txt` | All pages concatenated as markdown | RAG ingestion, large-context agents | | `/docs/.mdx` | Single page as raw markdown | Targeted reads — fetch exactly one page | When to Use Which [#when-to-use-which] * **Agent needs to find a page** — fetch `/llms.txt`, scan for the relevant title, then fetch that page's `.mdx` endpoint. * **Agent needs full context** — fetch `/llms-full.txt` and pass the entire corpus (or relevant chunks) into the context window. * **Agent already knows the page** — append `.mdx` to any docs URL to get raw markdown. For example, `/ai-agents/llms-txt.mdx` returns this page as markdown. The `/llms-full.txt` endpoint is large. If your agent has a limited context window, prefer `/llms.txt` to find the right page and then fetch it individually via `.mdx`. Fetching Examples [#fetching-examples] Page Index [#page-index] ```bash title="terminal" curl https://docs.across.to/llms.txt ``` ```ts title="agent.ts" const index = await fetch("https://docs.across.to/llms.txt").then(r => r.text()); console.log(index); ``` ```python title="agent.py" import requests index = requests.get("https://docs.across.to/llms.txt").text print(index) ``` Full Documentation Dump [#full-documentation-dump] ```bash title="terminal" curl https://docs.across.to/llms-full.txt ``` ```ts title="agent.ts" const full = await fetch("https://docs.across.to/llms-full.txt").then(r => r.text()); console.log(full); ``` ```python title="agent.py" import requests full = requests.get("https://docs.across.to/llms-full.txt").text print(full) ``` Single Page [#single-page] ```bash title="terminal" # Fetch the Swap API docs as markdown curl https://docs.across.to/introduction/swap-api.mdx ``` ```ts title="agent.ts" const page = await fetch("https://docs.across.to/introduction/swap-api.mdx") .then(r => r.text()); console.log(page); ``` ```python title="agent.py" import requests page = requests.get("https://docs.across.to/introduction/swap-api.mdx").text print(page) ``` Per-Page Actions [#per-page-actions] Every documentation page includes built-in buttons for AI consumption: * **Copy Markdown** — copies the page content as markdown to your clipboard * **Open in Claude / ChatGPT / Cursor** — opens the AI tool with the page URL pre-loaded as context These buttons appear at the top of each page and use the same `.mdx` endpoints described above. For RAG Pipelines [#for-rag-pipelines] The `/llms-full.txt` endpoint concatenates all pages with `# Title` headings. You can split on H1 headings to chunk by page: ```python title="chunker.py" import requests full_text = requests.get("https://docs.across.to/llms-full.txt").text # Split into per-page chunks chunks = [] current_chunk = "" for line in full_text.split("\n"): if line.startswith("# ") and current_chunk: chunks.append(current_chunk.strip()) current_chunk = line + "\n" else: current_chunk += line + "\n" if current_chunk.strip(): chunks.append(current_chunk.strip()) print(f"Split into {len(chunks)} page chunks") ``` Each chunk corresponds to one documentation page and can be embedded independently for retrieval. # MCP Server import { Callout } from 'fumadocs-ui/components/callout'; import { Tabs, Tab } from 'fumadocs-ui/components/tabs'; What is MCP? [#what-is-mcp] The [Model Context Protocol (MCP)](https://modelcontextprotocol.io) is an open standard that lets AI applications connect to external tools and data sources through a unified interface. The Across MCP server indexes Across documentation and exposes tools for searching docs, querying supported chains, fetching live bridge fees, and retrieving code examples — all from within your AI client. **Hosted instance available** — no local setup required. Point your client at `https://mcp.across.to/mcp` and you're ready to go. Connect to the Hosted Server [#connect-to-the-hosted-server] The fastest way to get started is to connect your AI client to the hosted MCP server. Edit your Claude Desktop config file: * **macOS**: `~/Library/Application Support/Claude/claude_desktop_config.json` * **Windows**: `%APPDATA%\Claude\claude_desktop_config.json` * **Linux**: `~/.config/Claude/claude_desktop_config.json` ```json title="claude_desktop_config.json" { "mcpServers": { "across-docs": { "url": "https://mcp.across.to/mcp" } } } ``` Restart Claude Desktop after saving. The Across tools will appear in the tool picker. ```bash title="terminal" claude mcp add --transport http across-docs https://mcp.across.to/mcp ``` Or add to your project's `.mcp.json`: ```json title=".mcp.json" { "mcpServers": { "across-docs": { "url": "https://mcp.across.to/mcp" } } } ``` Create or edit `.cursor/mcp.json` in your project (or `~/.cursor/mcp.json` for global): ```json title=".cursor/mcp.json" { "mcpServers": { "across-docs": { "url": "https://mcp.across.to/mcp" } } } ``` Add to `.vscode/settings.json`: ```json title="settings.json" { "mcp": { "servers": { "across-docs": { "url": "https://mcp.across.to/mcp" } } } } ``` Add to `~/.windsurf/mcp.json`: ```json title="mcp.json" { "mcpServers": { "across-docs": { "url": "https://mcp.across.to/mcp" } } } ``` Add to your MCP config: ```json title="mcp.json" { "mcpServers": { "across-docs": { "url": "https://mcp.across.to/mcp" } } } ``` Available Tools [#available-tools] Once connected, your AI agent has access to seven tools: | Tool | Description | | ---------------------- | ------------------------------------------------ | | `search_across_docs` | Full-text search across all Across documentation | | `get_page` | Retrieve a complete documentation page by path | | `get_api_reference` | Browse REST API endpoints and their parameters | | `get_supported_chains` | List mainnet and testnet chains with chain IDs | | `get_bridge_fees` | Query live bridge fees from the Across API | | `get_code_examples` | Get SDK and integration code samples | | `recrawl_docs` | Force a documentation refresh | Example Prompts [#example-prompts] Once configured, you can ask your AI agent things like: ``` Search the Across docs for how to do a crosschain swap ``` ``` What chains does Across Protocol support? ``` ``` What are the bridge fees to send USDC from Ethereum to Arbitrum? ``` ``` Show me code examples for using the Across SDK ``` ``` Show me the Across API endpoint for suggested fees ``` ``` How do I run an Across relayer? ``` Self-Hosting [#self-hosting] If you prefer to run the server locally instead of using the hosted instance: ```bash title="terminal" git clone https://github.com/across-protocol/mcp-server-across.git cd mcp-server-across npm install npm run build ``` Then point your client to the local build: ```json title="claude_desktop_config.json" { "mcpServers": { "across-docs": { "command": "node", "args": ["/absolute/path/to/mcp-server-across/dist/index.js"] } } } ``` ```bash title="terminal" claude mcp add across-docs node /absolute/path/to/mcp-server-across/dist/index.js ``` The server caches documentation locally at `~/.across-mcp/cache.json` and refreshes every 24 hours. Docker [#docker] ```bash title="terminal" docker build -t mcp-server-across . docker run -i mcp-server-across ``` With cache persistence: ```bash title="terminal" docker run -i -v across-mcp-cache:/root/.across-mcp mcp-server-across ``` Development [#development] ```bash title="terminal" npm run dev # watch mode npx @modelcontextprotocol/inspector node dist/index.js # test with MCP Inspector UI ``` Source Code [#source-code] The MCP server is open source: [github.com/across-protocol/mcp-server-across](https://github.com/across-protocol/mcp-server-across) # Prompt Library import { Callout } from 'fumadocs-ui/components/callout'; import { Tabs, Tab } from 'fumadocs-ui/components/tabs'; Prompts by Category [#prompts-by-category] Tested prompts organized by task category. Each prompt shows the natural-language instruction, the steps an agent should take, and the API endpoints involved. These prompts work best when the agent has the [Across skill installed](/ai-agents) or access to the [machine-readable documentation](/ai-agents/llms-txt). What chains does Across support? [#what-chains-does-across-support] **Prompt:** ``` What chains does Across support? List them with their chain IDs. ``` **Agent steps:** 1. Call `GET /swap/chains` 2. Format the response as a table of chain names and IDs **Endpoint:** `GET https://app.across.to/api/swap/chains` *** What tokens can I bridge from Arbitrum? [#what-tokens-can-i-bridge-from-arbitrum] **Prompt:** ``` What tokens can I bridge from Arbitrum using Across? ``` **Agent steps:** 1. Call `GET /swap/chains` to find Arbitrum's chain ID (42161) 2. Call `GET /swap/tokens?chainId=42161` 3. List all tokens with their symbols, addresses, and decimals **Endpoints:** `GET /swap/chains`, `GET /swap/tokens?chainId=42161` *** What are the limits for USDC? [#what-are-the-limits-for-usdc] **Prompt:** ``` What are the transfer limits for bridging USDC from Arbitrum to Base? ``` **Agent steps:** 1. Look up USDC addresses on both chains via `/swap/tokens` 2. Call `GET /swap/limits` with the token addresses and chain IDs 3. Report minimum and maximum transfer amounts **Endpoints:** `GET /swap/tokens`, `GET /swap/limits?originChainId=42161&destinationChainId=8453&inputToken=...&outputToken=...` Get a quote to bridge USDC [#get-a-quote-to-bridge-usdc] **Prompt:** ``` Get a quote to bridge 100 USDC from Arbitrum to Base. Show me the fees and estimated fill time. ``` **Agent steps:** 1. Look up chain IDs for Arbitrum (42161) and Base (8453) 2. Look up USDC addresses on both chains via `/swap/tokens` 3. Call `GET /swap/approval` with `amount=100000000` (100 USDC, 6 decimals) and `tradeType=minOutput` 4. Extract `fees`, `expectedFillTime`, and output amount from the response **Endpoint:** `GET /swap/approval?originChainId=42161&destinationChainId=8453&inputToken=...&outputToken=...&amount=100000000&depositor=...&tradeType=minOutput` *** Compare fees across routes [#compare-fees-across-routes] **Prompt:** ``` Compare the fees for bridging 1000 USDC from Ethereum to Arbitrum vs Ethereum to Base. ``` **Agent steps:** 1. Look up USDC addresses on Ethereum, Arbitrum, and Base 2. Call `/swap/approval` for Ethereum→Arbitrum with `amount=1000000000` 3. Call `/swap/approval` for Ethereum→Base with `amount=1000000000` 4. Compare `fees.totalFeeUsd` and `expectedFillTime` for both routes **Endpoint:** Two calls to `GET /swap/approval` with different `destinationChainId` values Bridge 100 USDC from Arbitrum to Base [#bridge-100-usdc-from-arbitrum-to-base] **Prompt:** ``` Bridge 100 USDC from Arbitrum to Base using my connected wallet. ``` **Agent steps:** 1. Call `GET /swap/chains` to confirm both chains are supported 2. Call `GET /swap/tokens?chainId=42161` and `GET /swap/tokens?chainId=8453` to find USDC addresses 3. Call `GET /swap/approval` with the route parameters and `depositor` set to the wallet address 4. Check `checks.balance` and `checks.allowance` on the response 5. Execute each transaction in `approvalTxns` (if any) 6. Execute `swapTx` — this is the bridge deposit **Endpoints:** `/swap/chains`, `/swap/tokens`, `/swap/approval` *** Handle approvals and execute [#handle-approvals-and-execute] **Prompt:** ``` I want to bridge 50 USDT from Ethereum to Optimism. Handle token approvals automatically. ``` **Agent steps:** 1. Discover chains and look up USDT addresses 2. Get a quote via `/swap/approval` 3. Check if `approvalTxns` is non-empty — if so, send each approval transaction and wait for confirmation 4. Send the `swapTx` transaction 5. Return the transaction hash and expected fill time **Endpoints:** `/swap/chains`, `/swap/tokens`, `/swap/approval` Check the status of a deposit [#check-the-status-of-a-deposit] **Prompt:** ``` Check the status of my bridge deposit with tx hash 0xabc123... on Arbitrum. ``` **Agent steps:** 1. Call `GET /deposit/status?originChainId=42161&depositTxHash=0xabc123...` 2. Report the status: `pending`, `filled`, or `expired` 3. If filled, show the fill transaction hash and destination chain **Endpoint:** `GET /deposit/status?originChainId=42161&depositTxHash=0xabc123...` *** Poll until filled [#poll-until-filled] **Prompt:** ``` Bridge 100 USDC from Arbitrum to Base and wait until the transfer is complete. ``` **Agent steps:** 1. Execute the full bridge flow (discover → quote → approve → execute) 2. After the deposit tx confirms, poll `GET /deposit/status` every 2 seconds 3. Continue polling until status is `filled` 4. Report the fill transaction hash and total time elapsed **Endpoints:** `/swap/chains`, `/swap/tokens`, `/swap/approval`, `/deposit/status` Bridge USDC and deposit into Aave [#bridge-usdc-and-deposit-into-aave] **Prompt:** ``` Bridge 100 USDC from Arbitrum to Ethereum, swap to ETH, and deposit into Aave's lending pool. ``` **Agent steps:** 1. Discover chains and look up USDC (Arbitrum) and WETH (Ethereum) addresses 2. Build an embedded action targeting Aave's WETH Gateway `depositETH()` function 3. Call `POST /swap/approval` with the `actions` array in the body and `recipient` set to the MulticallHandler contract 4. Execute approvals, then the swap transaction 5. The user receives an aWETH position on Ethereum **Endpoints:** `POST /swap/approval` with `actions` body Embedded actions require setting the `recipient` to the MulticallHandler contract address, not the user's wallet. The MulticallHandler receives the bridged tokens and executes the action on behalf of the user. *** Bridge ETH and add HubPool liquidity [#bridge-eth-and-add-hubpool-liquidity] **Prompt:** ``` Bridge ETH from Arbitrum to Ethereum and add it as liquidity to the Across HubPool. ``` **Agent steps:** 1. Look up the ETH/WETH addresses on both chains 2. Build an embedded action targeting the HubPool's `addLiquidity()` function 3. Call `POST /swap/approval` with the action and MulticallHandler as recipient 4. Execute the transaction — the user receives LP tokens on Ethereum **Endpoints:** `POST /swap/approval` with `actions` body # Chains & Contracts import { Callout } from 'fumadocs-ui/components/callout'; **Blast (Chain ID: 81457) — Deprecation Notice**
Across is deprecating support for the Blast chain (Chain ID: `81457`). Once it is disabled (targeting **20th July 2026**), Across routes to and from Blast will stop returning quotes, and the `/swap/chains` endpoint will stop listing Blast as a supported chain. Deployed Contracts [#deployed-contracts] # Guides import { Card, Cards } from 'fumadocs-ui/components/card'; Browse Guides [#browse-guides] Understand the fundamentals — crosschain intents, intent architecture, the intent lifecycle, and Across V4's ZK settlement. Hands-on integration guides for building with Across. Step-by-step migration references for Solana, CCTP, non-EVM chains, BNB, and V2→V3 upgrades. # API Reference import { Callout } from 'fumadocs-ui/components/callout'; import { Tabs, Tab } from 'fumadocs-ui/components/tabs'; **Blast (Chain ID: 81457) — Deprecation Notice**
Across is deprecating support for the Blast chain (Chain ID: `81457`). Once it is disabled (targeting **20th July 2026**), Across routes to and from Blast will stop returning quotes, and the `/swap/chains` endpoint will stop listing Blast as a supported chain. The Across API provides programmatic access to crosschain bridging and swap functionality. Use these endpoints to get quotes, check limits, query deposit status, and more. Server URLs [#server-urls] | Environment | Base URL | | ----------- | --------------------------- | | Production | `https://app.across.to/api` | Authentication [#authentication] All API requests require a Bearer token passed via the `Authorization` header, and an `integratorId` query parameter. Don't have an API key yet? [Get your API key and Integrator ID](/tools/integrator-id) in under a minute. Using API Keys [#using-api-keys] Pass your API key as a `Bearer` token in the `Authorization` header on every request. ```bash curl -H "Authorization: Bearer YOUR_API_KEY" \ "https://app.across.to/api/swap/approval?originChainId=42161&destinationChainId=8453&inputToken=0xaf88d065e77c8cC2239327C5EDb3A432268e5831&outputToken=0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913&amount=10000000&tradeType=minOutput&depositor=0xYourAddress&integratorId=0xdead" ``` ```ts const res = await fetch( "https://app.across.to/api/swap/approval?originChainId=42161&destinationChainId=8453&inputToken=0xaf88d065e77c8cC2239327C5EDb3A432268e5831&outputToken=0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913&amount=10000000&tradeType=minOutput&depositor=0xYourAddress&integratorId=0xdead", { headers: { Authorization: "Bearer YOUR_API_KEY" }, } ); ``` ```python import requests response = requests.get( "https://app.across.to/api/swap/approval", params={ "originChainId": "42161", "destinationChainId": "8453", "inputToken": "0xaf88d065e77c8cC2239327C5EDb3A432268e5831", "outputToken": "0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913", "amount": "10000000", "tradeType": "minOutput", "depositor": "0xYourAddress", "integratorId": "0xdead", }, headers={"Authorization": "Bearer YOUR_API_KEY"}, ) ``` ```go req, _ := http.NewRequest("GET", "https://app.across.to/api/swap/approval?originChainId=42161&destinationChainId=8453&inputToken=0xaf88d065e77c8cC2239327C5EDb3A432268e5831&outputToken=0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913&amount=10000000&tradeType=minOutput&depositor=0xYourAddress&integratorId=0xdead", nil) req.Header.Set("Authorization", "Bearer YOUR_API_KEY") resp, _ := http.DefaultClient.Do(req) ``` ```rust let res = reqwest::Client::new() .get("https://app.across.to/api/swap/approval?originChainId=42161&destinationChainId=8453&inputToken=0xaf88d065e77c8cC2239327C5EDb3A432268e5831&outputToken=0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913&amount=10000000&tradeType=minOutput&depositor=0xYourAddress&integratorId=0xdead") .header("Authorization", "Bearer YOUR_API_KEY") .send() .await?; ``` ```ruby uri = URI("https://app.across.to/api/swap/approval?originChainId=42161&destinationChainId=8453&inputToken=0xaf88d065e77c8cC2239327C5EDb3A432268e5831&outputToken=0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913&amount=10000000&tradeType=minOutput&depositor=0xYourAddress&integratorId=0xdead") req = Net::HTTP::Get.new(uri) req["Authorization"] = "Bearer YOUR_API_KEY" res = Net::HTTP.start(uri.hostname, uri.port, use_ssl: true) { |http| http.request(req) } ``` Endpoints [#endpoints] Browse the individual endpoint pages in the sidebar for full parameter details, response schemas, and code samples. # Actors in the System import { Callout } from 'fumadocs-ui/components/callout'; Across is a multi-actor system where each participant plays a distinct role in making crosschain transfers fast, secure, and capital-efficient. Understanding these roles helps you reason about the protocol's trust assumptions and economic incentives. User [#user] Users initiate crosschain transfers by submitting deposit orders to a SpokePool on the origin chain. They pay fees to relayers and liquidity providers in exchange for near-instant token delivery on the destination chain. Users interact with the protocol through: * The [Swap API](/introduction/swap-api) (most common) * [ERC-7683](/guides/concepts/erc-7683) `open()` calls * Direct `depositV3()` calls on SpokePool contracts Relayer [#relayer] Relayers are the actors that make \~2 second fills possible. When a user deposits on the origin chain, relayers **front their own capital** on the destination chain to fill the intent immediately, then wait for reimbursement through the settlement process. How Relayers Work [#how-relayers-work] 1. Monitor origin SpokePools for `V3FundsDeposited` events 2. Evaluate profitability (fees vs. gas costs and capital lock-up) 3. Call `fillV3Relay()` on the destination SpokePool using their own tokens 4. Request repayment on any Across-supported chain (not necessarily the origin chain) 5. Receive the user's `inputAmount` minus the LP fee after bundle settlement Relayer Risks [#relayer-risks] Relayer fees compensate for real costs and risks: | Risk | Description | | ------------------- | ------------------------------------------------------------ | | **Gas costs** | Submitting fill transactions on destination chains | | **Capital lock-up** | Funds are locked until bundle settlement (\~1.5 hours) | | **Software bugs** | Errors in relayer implementation could lead to invalid fills | | **Finality risk** | Chain reorganizations could revert confirmed fills | Permissionless Participation [#permissionless-participation] Running a relayer is **permissionless** — anyone can operate one. Risk Labs provides [open-source relayer software](https://github.com/across-protocol/relayer-v3), though developers can customize behavior or build alternative implementations. Exclusive Relayers [#exclusive-relayers] For some intents, a relayer may have **exclusive fill rights** during an exclusivity period. This is determined by the `exclusiveRelayer` and `exclusivityDeadline` fields in the deposit. After the exclusivity window expires, any relayer can fill. Liquidity Provider (LP) [#liquidity-provider-lp] LPs deposit assets into pools on Ethereum mainnet at [across.to/pool](https://across.to/pool). This capital serves two purposes: 1. **Repayment flexibility** — Relayers can request repayment on any chain. LP capital ensures the HubPool can rebalance funds across SpokePools to honor these requests 2. **Backup fulfillment** — In rare cases where no relayer fills a deposit, LP capital can be used to fulfill the transfer directly LP Risks [#lp-risks] | Risk | Description | | ----------------------- | ------------------------------------------------------------ | | **Capital deployment** | Deposited capital is actively used for rebalancing and fills | | **Liquidity risk** | High demand periods may temporarily prevent withdrawals | | **Smart contract risk** | Standard DeFi smart contract risk | LP Fee Model [#lp-fee-model] LPs earn fees based on pool utilization — the more the pool is used for crosschain rebalancing, the higher the LP fee percentage. See [Fees in the System](/introduction/fees) for details on the utilization-based pricing model. Dataworker [#dataworker] The dataworker is a **whitelisted** off-chain actor that coordinates settlement between all chains. It aggregates fills into **bundles** and proposes them to the HubPool on Ethereum. What the Dataworker Does [#what-the-dataworker-does] 1. **Determines block ranges** for each supported chain 2. **Validates fills** against deposits across all chains 3. **Aggregates** valid fills into payment lists 4. **Computes** crosschain transfer instructions for rebalancing 5. **Organizes** everything into merkle trees 6. **Proposes** the bundle to the HubPool with a bond Bundles [#bundles] A bundle is a set of merkle roots encoding: * Relayer refund instructions (which relayers to pay, how much, on which chain) * Token rebalancing instructions (how to move funds between SpokePools) * Slow fill instructions (for deposits that weren't filled by relayers) Bundles are proposed every **\~1.5 hours minimum**. After proposal, they enter a challenge period where anyone can dispute them. Settlement cost is **O(1)**, not O(N). No matter how many individual fills happen in a period, they're aggregated into a single bundle proposal. This is what makes Across gas-efficient at scale. Dataworker Rules [#dataworker-rules] Dataworker behavior is precisely defined by **UMIP-157** and **UMIP-179** — UMA Improvement Proposals that specify exactly how bundles must be constructed. Any deviation from these rules can be disputed. UMA Optimistic Oracle [#uma-optimistic-oracle] The UMA Optimistic Oracle provides the economic security layer for Across. It verifies that proposed bundles are valid through an **optimistic verification** mechanism. How It Works [#how-it-works] 1. The dataworker proposes a bundle and posts a bond 2. The bundle enters a **challenge period** 3. During this period, anyone can dispute the bundle by also posting a bond 4. If no dispute occurs, the bundle is finalized and executed 5. If disputed, UMA's **Data Verification Mechanism (DVM)** resolves it — UMA token holders vote on whether the bundle was valid Trust Assumption [#trust-assumption] The system only needs **a single honest actor** willing to dispute invalid proposals to remain secure. This is a much weaker trust assumption than requiring a majority of validators to be honest. See [Security Model](/introduction/security) for more details on the verification and dispute process. # API Keys & Integrator ID import { Callout } from 'fumadocs-ui/components/callout'; import { Tabs, Tab } from 'fumadocs-ui/components/tabs'; What Are They? [#what-are-they] Production use of Across requires two credentials: | Credential | What it is | How it's used | | ----------------- | --------------------------------------------- | ------------------------------------------------------------------------------------------------------------------ | | **API Key** | Authentication token for API requests | Passed in the `Authorization` header on every API call | | **Integrator ID** | Unique 2-byte hex identifier (e.g., `0xdead`) | Passed as a query parameter (`integratorId`) in API calls, or appended to calldata for direct contract integration | Both are required for production. Without them, your requests may be rate-limited or rejected. How to Request [#how-to-request] **[Get your API key and Integrator ID](/tools/integrator-id)** — register your project and receive your credentials instantly. Using with the Swap API [#using-with-the-swap-api] When calling the Swap API, pass **both** your API key in the `Authorization` header and your integrator ID as a query parameter: ```ts title="swap-api-auth.ts" const params = new URLSearchParams({ tradeType: "minOutput", originChainId: "42161", destinationChainId: "8453", inputToken: "0xaf88d065e77c8cC2239327C5EDb3A432268e5831", outputToken: "0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913", amount: "1000000000", depositor: "0xYourWalletAddress", integratorId: "0xdead", // Your 2-byte hex integrator ID }); const response = await fetch( `https://app.across.to/api/swap/approval?${params}`, { headers: { Authorization: "Bearer YOUR_API_KEY", }, } ); ``` Using with Direct Contract Integration [#using-with-direct-contract-integration] If you're calling `depositV3` on the SpokePool directly (via the `suggested-fees` API), the credentials are passed differently: * **API key** — `Authorization` header on the `/suggested-fees` API call * **Integrator ID** — appended to the `depositV3` transaction **calldata** (not as a query parameter) Appending Integrator ID to Calldata [#appending-integrator-id-to-calldata] Append a **delimiter** (`1dc0de`) followed by your **integrator ID** to the end of the encoded `depositV3` calldata: | Component | Value | Description | | ----------------- | ------------------------------- | -------------------------------------------------------------- | | **Delimiter** | `1dc0de` | Fixed 3-byte hex string that marks the start of the identifier | | **Integrator ID** | Your assigned ID (e.g., `f001`) | Unique identifier provided by the Across team | ``` ...0000000000000000000000000000000000000000000000000000000000000000 // last param 1dc0def001 // ← delimiter (1dc0de) + integrator ID (f001) ``` **Do NOT** pass the delimiter + identifier to any `depositV3` parameter, including the `message` param. Only append it to the raw calldata of the transaction. **Do NOT** use `f001` as your identifier — it is an example only. Request your unique identifier from the Across team via your shared communication channel (Telegram, Slack). ```ts title="append-integrator-id.ts" import { encodeFunctionData, type Hex } from "viem"; const DELIMITER = "1dc0de"; const INTEGRATOR_ID = "f001"; // Replace with your assigned ID // Encode depositV3 calldata normally const calldata = encodeFunctionData({ abi: spokePoolAbi, functionName: "depositV3", args: [depositor, recipient, inputToken, outputToken, inputAmount, outputAmount, destinationChainId, exclusiveRelayer, quoteTimestamp, fillDeadline, exclusivityDeadline, message], }); // Append delimiter + integrator ID to the raw calldata const calldataWithId = `${calldata}${DELIMITER}${INTEGRATOR_ID}` as Hex; const hash = await walletClient.sendTransaction({ to: spokePoolAddress, data: calldataWithId, }); ``` Testnet vs Production [#testnet-vs-production] | Environment | Base URL | API Key Required? | | -------------- | ------------------------------- | ----------------- | | **Testnet** | `https://testnet.across.to/api` | No | | **Production** | `https://app.across.to/api` | Yes | **Testnet does not require an API key or integrator ID.** You can develop and test your integration freely on testnet without credentials. Only production requests need authentication. Rate Limits [#rate-limits] Without a valid API key, production requests are subject to strict rate limits. Authenticated requests receive higher rate limits appropriate for production traffic. If you're seeing `429 Too Many Requests` errors: * Verify your API key is included in the `Authorization` header * Check that the key is valid and not expired * Avoid polling `/swap/approval` or `/suggested-fees` more frequently than needed — these endpoints return fresh quotes, not cached data Integrator ID Format [#integrator-id-format] The integrator ID is a **2-byte hex string** prefixed with `0x` when used as a query parameter: ``` 0xdead ✓ Valid 0x0001 ✓ Valid 0xffff ✓ Valid dead ✗ Missing 0x prefix 0xdeadbeef ✗ Too long (4 bytes) ``` When appending to calldata for direct contract integration, use the raw hex without the `0x` prefix (e.g., `dead` not `0xdead`). # Audits Across Audit References [#across-audit-references] * [Across V3 Incremental Audit](https://blog.openzeppelin.com/across-v3-and-oval-incremental-audit) * [Across V3 Audit](https://blog.openzeppelin.com/across-v3-incremental-audit?hs_preview=lerUtAnm-157915368784) * [Across Token and Token Distributor Audit](https://blog.openzeppelin.com/across-token-and-token-distributor-audit/) * [Across V2 Audit](https://blog.openzeppelin.com/uma-across-v2-audit/) UMA Audit References [#uma-audit-references] * [UMA's Continuous Audit (Optimistic Oracle)](https://blog.openzeppelin.com/uma-continuous-audit/) * [UMA Audit – L2 Bridges](https://blog.openzeppelin.com/uma-audit-l2-bridges/) * [UMA Audit – Phase 4](https://blog.openzeppelin.com/uma-audit-phase-4/) * [UMA Audit – Phase 6](https://blog.openzeppelin.com/uma-audit-phase-6/) # The Bridge Across The $ACX Exchange portal is not live yet. Follow [@AcrossProtocol on X](https://x.com/AcrossProtocol) for the launch announcement and the latest details. Overview [#overview] "The Bridge Across" is a [governance proposal](https://forum.across.to/t/the-bridge-across/2097) from Risk Labs to move Across from a token-based DAO to a private U.S. C-corporation ("AcrossCo"). The goal is to explore new growth opportunities for Across. The proposal [passed its Snapshot vote](https://snapshot.box/#/s:acrossprotocol.eth/proposal/0x4a3b1bdaf7cf8df8a04827fbe9fbc8df36274e595585e7a4bb6744652044d9d5) and the work is underway. As part of the transition, $ACX holders will be offered a way to exchange their $ACX through a dedicated portal. Full terms will be shared ahead of launch. This page is a short summary with links to the primary sources. It is not legal, financial, or tax advice. Preparing [#preparing] Taking part will require holding $ACX in a wallet whose private keys you control, rather than on a centralized exchange. The [guide to moving your $ACX off exchanges](https://across.to/blog/how-to-move-your-acx-off-exchanges) walks through setting up a wallet, withdrawing, and confirming the tokens arrived. **Beware of scams.** The portal link will only ever be announced through Across' official channels. Do not connect your wallet to a "portal" you found in a DM, reply, or search ad, and never share your seed phrase. Links [#links] The proposal and the community discussion around it. Where the exchange portal currently stands. Getting your $ACX into a self-custody wallet. Stay updated [#stay-updated] Announcements, including the portal launch and the full terms, go out on [@AcrossProtocol on X](https://x.com/AcrossProtocol) first. # Bug Bounty Security of the platform is our highest priority. All smart contracts and off-chain code (i.e. most of the code within the `across-protocol` [repository](https://github.com/across-protocol)) are within scope and are publicly verifiable. Security researchers are eligible for a bug bounty for reporting undiscovered vulnerabilities. Bounty Program [#bounty-program] We encourage the community to audit our open source code; we also encourage the responsible disclosure of any issues. The bug bounty program is intended to recognize the value of working with the community of independent security researchers and sets out our definition of good faith in the context of finding and reporting vulnerabilities, as well as what you can expect from us in return. Across offers substantial rewards for discoveries that can prevent the loss of assets, the freezing of assets, or harm to users. To be eligible for a bounty, a bug must have not been previously known by the Across team or publicly disclosed by anyone. All Across smart contracts and interactions (including bots and front end code) are in scope. The amount of compensation will vary depending on bug severity. Reward amounts typically correspond to severity in the following manner. The reward currency can be discussed on a case by case basis. | Severity | Reward | | -------- | ---------------: | | Low | $250 | | Medium | $1,000 | | High | $10,000 | | Critical | up to $1,000,000 | Severity is calculated according to the [OWASP](https://owasp.org/www-project-risk-assessment-framework/) risk rating model based on Impact and Likelihood. Submissions [#submissions] Please email your submissions to [bugs@across.to](mailto:bugs@across.to). The submission must include clear and concise steps to reproduce the discovered vulnerability. The following layout of the bug bounty report is encouraged: * **Description:** Describe at a high level the bug with links to problematic code * **Attack:** Detailed instructions for exploiting the bug * **Mitigation:** How to resolve the bug * **Suggested risk rating:** The recommended severity of this bug Terms & Conditions [#terms--conditions] The [same terms and conditions](https://docs.umaproject.org/resources/audit-and-bug-bounty-programs) from the UMA bug bounty program apply here. # Direct Route Linking import { Callout } from 'fumadocs-ui/components/callout'; Across's frontend supports **direct route linking** — construct a URL with query parameters to drop users directly into a pre-filled bridge route. No API calls, no wallet connection required upfront. How It Works [#how-it-works] Append query parameters to the base URL to pre-select the origin chain, destination chain, and tokens: ``` https://app.across.to/bridge-and-swap?from=8453&to=42161&inputToken=BAL&outputToken=USDC ``` Direct route linking This opens the Across bridge with **Base → Arbitrum** selected and **BAL → USDC** as the token pair. | Parameter | Description | Example | | ------------- | -------------------- | ------- | | `from` | Origin chain ID | `8453` | | `to` | Destination chain ID | `42161` | | `inputToken` | Input token symbol | `BAL` | | `outputToken` | Output token symbol | `USDC` | All parameters are optional — use any combination. For the full parameter reference, examples, chain ID table, and use cases, see the [complete guide](/guides/user-guides/direct-route-linking). # Technical FAQ import { Accordion, Accordions } from 'fumadocs-ui/components/accordion'; import { Callout } from 'fumadocs-ui/components/callout';
Getting Started [#getting-started]
We recommend using the **Swap API** for most integrations — it's the most flexible and well-documented path. * **[Swap API](/introduction/swap-api)** — Full control over the bridging flow. Ideal for wallets, dApps, aggregators, and backend services. * **[App SDK](/guides/dev-guides/integrate-swap-api)** — TypeScript SDK that wraps the API. Good for quick prototyping. Start with the [step-by-step integration guide](/guides/dev-guides/integrate-swap-api) to get up and running.
**Yes.** API keys should never be exposed in client-side code — they can be extracted from browser network requests and abused. Move your Across API calls to a server-side route (e.g. a Next.js API route, Express endpoint, or serverless function) and pass the API key there via the `Authorization` header. Beyond security, API keys and Integrator IDs are important because they help us: * **Track your usage** — so we can provide you with analytics and support * **Monitor for anomalies** — if your integration gets attacked or experiences unusual traffic, we can detect it early and alert you * **Prioritize your requests** — authenticated requests receive higher rate limits suitable for production traffic [Get your API key and Integrator ID](/tools/integrator-id) if you haven't already.
**No.** Testnet endpoints do not require authentication. You can develop and test your integration freely without credentials. Only production requests need an API key. See [API Keys & Integrator ID](/introduction/api-keys) for details on environments and rate limits.
When using the legacy `/suggested-fees` API with direct `depositV3` SpokePool calls, credentials are passed differently than the Swap API: * **API key** — pass as a `Bearer` token in the `Authorization` header on the `/suggested-fees` request itself * **Integrator ID** — append to the `depositV3` transaction **calldata** (not as a query parameter) To append the Integrator ID, add a **delimiter** (`1dc0de`) followed by your **ID** to the end of the encoded calldata: ``` ...0000000000000000 // last depositV3 param 1dc0def001 // ← delimiter (1dc0de) + integrator ID (f001) ``` ```ts import { encodeFunctionData, type Hex } from "viem"; const DELIMITER = "1dc0de"; const INTEGRATOR_ID = "f001"; // Replace with your assigned ID const calldata = encodeFunctionData({ abi: spokePoolAbi, functionName: "depositV3", args: [depositor, recipient, inputToken, outputToken, inputAmount, outputAmount, destinationChainId, exclusiveRelayer, quoteTimestamp, fillDeadline, exclusivityDeadline, message], }); const calldataWithId = `${calldata}${DELIMITER}${INTEGRATOR_ID}` as Hex; ``` **Important:** Do NOT pass the delimiter + ID to any `depositV3` parameter (including `message`). Only append it to the raw calldata. Do NOT use `f001` — it's an example. [Get your own ID](/tools/integrator-id). Full details at [API Keys & Integrator ID — Legacy Suggested Fees](/introduction/api-keys). > **Warning:** The `/suggested-fees` API is legacy and will be sunset. New integrations should use the [Swap API (`/swap/approval`)](/api-reference/swap/approval/get) instead, which handles the Integrator ID as a simple query parameter — no calldata appending needed. See [Migrate from Suggested Fees to the Swap API](/guides/migration/suggested-fees-to-swap) for a step-by-step guide.
Token Behavior [#token-behavior]
Depending on the context, Across will sometimes send a user ETH and sometimes send a user WETH: | Input Asset | Recipient Type | Received | | ----------- | -------------- | -------- | | **ETH** | EOA (wallet) | **ETH** | | **ETH** | Contract | **WETH** | | **WETH** | EOA (wallet) | **ETH** | | **WETH** | Contract | **WETH** | This behavior is automatic — you don't need to handle wrapping/unwrapping yourself. See the [Swap API docs](/introduction/swap-api) for more details.
To deposit **ETH** (or the native token for a network), set `msg.value = inputAmount`. To deposit **WETH**, set `msg.value = 0`. In both cases, the `inputAmount` should be the same and the `inputToken` should be the **WETH address** for the current chain. ```ts // ETH deposit await contract.deposit({ ..., value: inputAmount }); // WETH deposit await contract.deposit({ ..., value: 0n }); ``` Find WETH addresses per chain via [/swap/tokens](/api-reference/swap/tokens/get).
Deposits & Refunds [#deposits--refunds]
Don't panic — your funds are safe. Here's what to do: 1. **Check the status** using the [Status Tracker](/tools/status-tracker) tool or the [deposit status API](/api-reference/deposit/status/get) 2. **If `pending`** — the transfer is still being processed. Most deposits fill in \~2 seconds, but it can take longer during congestion 3. **If `expired`** — a refund is being processed automatically. See [Refunds](/introduction/refunds) for timing (\~120-150 minutes) 4. **If stuck for >3 hours** — reach out via [Telegram](https://t.me/acrosstg), [in-app support](https://across.to), or Slack Note: refunds are only issued on mainnet deposits.
Recommended `fillDeadline` is **6 hours** from the time of deposit. This ensures the best experience for the user, especially in tricky situations where a deposit is being [slow filled](/guides/concepts/intent-lifecycle). A shorter `fillDeadline` risks the deposit expiring before it can be filled during periods of high congestion or relayer downtime. See [Refunds](/introduction/refunds) for what happens when a deposit expires.
Refund timing after a deposit expires: | Metric | Time after deposit | | ----------- | ------------------ | | **Minimum** | \~120 minutes | | **Typical** | \~135 minutes | | **Maximum** | \~150 minutes | Components: fill deadline (\~90 min) + bundle processing (\~30 min) + canonical bridge delay (\~5-30 min). If your refund hasn't arrived after **3 hours**, reach out to the team. Full details at [Refunds](/introduction/refunds).
Deposit Addresses [#deposit-addresses]
It still works. Deposit addresses are **amount agnostic** — the address is tied to the route (origin/destination chain, tokens, recipient, refund address), not to a specific amount. The sweeper bot re-quotes at sweep time using the actual balance that arrived at the address, so users can send more or less than originally quoted and the bridge will still execute. The output will reflect the amount actually sent and the fee bounds locked in at quote time. Amount agnostic does not mean unbounded: for [`POST /deposit-addresses`](/api-reference/deposit-addresses/post), the amount must still fall within the `limits` (`minInputAmount` / `maxInputAmount`) of the `supportedInputs[]` entry matching the origin chain and token you send. Amounts outside those bounds are refunded rather than swept. See [Persistent Deposit Addresses](/introduction/persistent-deposit-addresses) for more details.
No. Addresses returned by [`POST /deposit-addresses`](/api-reference/deposit-addresses/post) are **persistent and never expire** — `expiresAt` is always `null`. The same request parameters always resolve to the same address, so you can request it once and reuse it indefinitely. What bounds a transfer is the route, not the clock. A deposit is swept automatically when its origin chain and token match an entry in the response's `supportedInputs[]` **and** the amount falls inside that entry's `limits` (`minInputAmount` / `maxInputAmount`). A deposit outside those bounds can't be completed and takes the refund path — automatic to your `refundAddresses` if you supplied them, manual recovery via support if you didn't. `supportedInputs[]` changes as origin chains and limits are added, so re-POST before a reuse that depends on limits you read earlier: you get the same address back, with a current list. If a transfer that satisfied those bounds hasn't been swept, it is **not** because the address expired. Reach out to the team with your `depositAddress` and the transfer transaction hash via [Telegram](https://t.me/acrosstg), [in-app support](https://across.to), or Slack. Addresses issued by the deprecated `GET /swap/counterfactual` endpoint did carry a 24-hour TTL, and funds sent after expiry were not processed automatically. That limit never applied to `POST /deposit-addresses`. Migrating off the legacy endpoint depends on your destination. [`POST /deposit-addresses`](/api-reference/deposit-addresses/post) now covers 20 destination chains — see [Supported routes](/introduction/persistent-deposit-addresses#supported-routes) — so most integrations can move across. See [Persistent Deposit Addresses](/introduction/persistent-deposit-addresses) for the full flow.
All scenarios require manual recovery — reach out to the team with your `depositAddress`, the token address you sent, and the chain ID where funds were sent. | Scenario | Outcome | | -------------------------- | ------------------------ | | Correct token, wrong chain | Manual recovery required | | Wrong token, correct chain | Manual recovery required | | Wrong token, wrong chain | Manual recovery required | Full details at [Persistent Deposit Addresses](/introduction/persistent-deposit-addresses).
***

Still have questions?

Our team is here to help. Reach out on any of these channels.

# Key Features import { Callout } from 'fumadocs-ui/components/callout'; import { Card, Cards } from 'fumadocs-ui/components/card'; Integration methods [#integration-methods] Across supports three integration methods. The [**Swap API**](/introduction/swap-api) is the default and covers most use cases. | Method | What it is | Use when | | ----------------------------------------------------------------- | --------------------------------------------------------------------------------------- | ---------------------------------------------- | | [**Swap API**](/introduction/swap-api) *(primary)* | Quote a route, then execute the returned transaction from the user's wallet | All Standard integrations — the primary path | | [**Gasless**](/api-reference/swap/gasless/get) | The user signs a message; Across submits the transaction on-chain, no gas from the user | You want users to transact without holding gas | | [**Deposit address**](/introduction/persistent-deposit-addresses) | Send funds to a persistent infinite-TTL address to conduct a crosschain swap | automation, on-ramps, deposit flows | Feature Highlights [#feature-highlights] | Feature | Details | | ---------------------------------------- | ---------------------------------------------------------------------------------------------------------- | | **Sub-2-second fills** | Competitive relayer network delivers funds on the destination chain in \~2 seconds on mainnet | | **24 mainnet chains** | Solana, MegaETH, Plasma, Monad, Hyperliquid, and all major L2s | | **CCTP V2 / CCTPFast** | Native USDC settlement up to $10M per transaction. CCTPFast offers faster attestation where available | | **Sponsored routes** | Zero-fee USDT/USDT0 → USDC-SPOT/USDC-PERPS on HyperCore from Ethereum, Arbitrum, Monad, Polygon, Unichain. | | **Embedded crosschain actions** | Compose DeFi operations — swap, bridge, and execute destination-chain calls in a single transaction | | **OFT for USDT0** | Native USDT0 mint-and-burn settlement via LayerZero. More tokens coming soon | | **ERC-7683 standard** | Implements the crosschain intent standard for interoperability with other intent-based systems | | **ZK proofs** | Succinct/SP1 zero-knowledge proofs enable permissionless chain expansion without governance votes | API Comparison [#api-comparison] The three main APIs for initiating crosschain transfers are [`/swap/approval`](/api-reference/swap/approval/get), [`/swap/gasless`](/api-reference/swap/gasless/get), and [`/deposit-addresses`](/api-reference/deposit-addresses/post) — sign and submit a transaction, sign one gasless message, or send funds to a persistent address. They serve different use cases and have different capabilities. | Features | `/swap/approval` | `/swap/gasless` | `/deposit-addresses` | | -------------------------------- | -------------------------------------------------------------- | --------------------------------------------------------------------------------------------------------------------- | ---------------------------------------------------------------------------------------------- | | **How it works** | Returns a transaction for the user to sign and submit on-chain | User signs one EIP-712 message (ERC-3009 / Permit2 permit); a submitter broadcasts it on-chain — no gas from the user | Returns a persistent deposit address to send tokens to — no signing or per-transfer quote | | **HTTP methods** | `GET` (simple bridge) / `POST` (embedded actions) | `GET` to quote → `POST /gasless/submit` with the signature | `POST` only | | **API key required** | Yes | Yes | Yes | | **Integrator ID required** | Yes | Yes | Yes | | **Supported origin chains** | All 24 mainnet chains | Any Across-supported EVM chain (plus HyperCore via `1337`) | 17 chains — discovered dynamically, read `supportedInputs[]` from the response (not hardcoded) | | **Supported destination chains** | All 24 mainnet chains | Any Across-supported EVM chain (plus HyperEVM `999`) | 20 chains — the 17 origin chains plus HyperCore (`1337`) | | **Supported tokens (origin)** | All bridgeable tokens (per `/swap/tokens`) | Tokens that support gasless authorization (ERC-3009 / Permit2 — e.g. USDC) | Route-specific — stablecoins, ETH/WETH and WBTC where the route carries them | | **Trade types** | `exactInput`, `minOutput`, `exactOutput` | `exactInput`, `exactOutput` | N/A — amount-agnostic (the amount isn't part of the request) | | **Embedded crosschain actions** | Yes (via `POST` with `crossChainMessage`) | No | No | | **Origin swaps** | Yes (automatic if input token is not directly bridgeable) | Yes (any-input routes, e.g. USDC → native ETH) | No | | **Refund mechanism** | Automatic via SpokePool to `refundAddress` | Origin or destination by route (`refundOnOrigin`); paid to `refundAddress` → `recipient` → `depositor` | Refunds to `refundAddresses` if a deposit can't complete | | **Ideal for** | Wallets, dApps, DEX aggregators — any flow with wallet signing | Onboarding users with no gas or native token; embedded wallets; HyperCore withdrawals | CEX onramps, bots, automation, recurring deposits — flows with no wallet signing | | **Expected fill time** | Less than 2 seconds | Less than 2 seconds | Provided per route via `indicativeFillTime` in the response | | **Deposit address TTL** | N/A | N/A | Never expires — `expiresAt` is always `null` | | **Status** | Generally available | Generally available | Gated ([request access](https://t.me/acrosstg)) | Speed [#speed] Across's infrastructure fills most transfers in **\~2 seconds** on all supported chains, so funds reach the recipient on the destination chain almost immediately. Chain Coverage [#chain-coverage] Across supports **24 mainnet chains** including: * **EVM L2s** — Arbitrum, Optimism, Base, Polygon and more * **Alt-L1s and new chains** — Solana, MegaETH, Plasma, Monad * **App-specific chains** — Hyperliquid (HyperCore + HyperEVM) * **Testnet support** — 8 testnet chains for development See the full list [here](/chains-and-contracts). Sponsored Routes [#sponsored-routes] Select routes have zero bridge fees, subsidized by the protocol or partners. **Currently sponsored:** * **USDT / USDT0 → USDC-SPOT, USDC-PERPS** on HyperCore from Ethereum, Arbitrum, Monad, Polygon, Unichain Sponsored routes change over time. Check the `/swap/approval` response for fee breakdowns to see if a route is currently sponsored. Embedded Crosschain Actions [#embedded-crosschain-actions] Bridge and execute any arbitrary action (like swap, mint, deposit etc.) in one transaction. Attach arbitrary contract calls to your crosschain transfer — the [MulticallHandler](/introduction/embedded-actions) executes them atomically on the destination chain. Use cases: * Swap + deposit into Aave * Bridge + add liquidity to a DEX * Transfer + stake on the destination chain # Fees in the System import { Callout } from 'fumadocs-ui/components/callout'; Every crosschain transfer through Across incurs fees that compensate the actors making the system work — liquidity providers and relayers. All fees are derived from the spread between the `inputAmount` (what the user deposits on the origin chain) and the `outputAmount` (what the user receives on the destination chain). Fee Breakdown [#fee-breakdown] The total fee a user pays is the difference between their deposit and what they receive: ``` totalFee = inputAmount - outputAmount ``` This total fee is split between two components: | Fee Type | Recipient | Purpose | | --------------- | ---------------------------- | ------------------------------------------------------------ | | **LP Fee** | Liquidity providers | Compensates LPs for capital utilization and rebalancing risk | | **Relayer Fee** | Relayer who fills the intent | Covers gas costs, capital opportunity cost, and risk | Use the `/suggested-fees` endpoint to get a fee quote before executing a transfer. The response breaks down each component. `/suggested-fees` is **legacy**. New integrations should read fees off the [`/swap/approval`](/api-reference/swap/approval/get) response instead. Already on it? See [Migrate from Suggested Fees to the Swap API](/guides/migration/suggested-fees-to-swap). LP Fees [#lp-fees] Across uses a **utilization-based pricing model** adapted from lending protocols like Aave. LP fees depend on how much of the available liquidity pool is being used. How It Works [#how-it-works] * When utilization is low, LP fees are minimal — plenty of capital is available * As utilization increases, fees rise along a curve to incentivize more LP deposits * Above a "kink" threshold, fees increase steeply to discourage draining the pool Key Variables [#key-variables] | Variable | Description | | --------- | --------------------------------------------------------- | | **U** | Current pool utilization (0 to 1) | | **U-bar** | Kink utilization — threshold where the fee curve steepens | | **R0** | Base interest rate | | **R1** | Slope below kink | | **R2** | Slope above kink (steep) | The annualized rate formula follows an Aave-style two-slope model: ``` R(U) = R0 + (min(U-bar, U) / U-bar) * R1 + (max(0, U - U-bar) / (1 - U-bar)) * R2 ``` Weekly rates are derived as `(1 + R_annual)^(1/52) - 1`, and the final LP fee is the weekly rate multiplied by the transaction size. **When are LP fees zero?** If the relayer takes repayment on the origin chain (same chain as the deposit), no crosschain rebalancing is needed, so LP fees are zero. Non-zero fees apply when repayment occurs on a different chain. Per-Route Parameters [#per-route-parameters] The rate parameters (R0, R1, R2, U-bar) vary by token and route. This means the LP fee for bridging USDC from Arbitrum to Base may differ from USDC from Ethereum to Optimism, reflecting different pool utilization levels. Relayer Fees [#relayer-fees] Relayers are compensated for three costs they incur when filling an intent: 1. Gas Fees [#1-gas-fees] The cost of submitting the fill transaction on the destination chain. This varies by chain — filling on Ethereum L1 costs more gas than filling on Arbitrum or Base. 2. Capital Opportunity Cost [#2-capital-opportunity-cost] Relayers lock their own capital to fill intents immediately, then wait for reimbursement through the bundle settlement process (\~1.5 hours). The fee compensates for the time value of that locked capital. 3. Capital at Risk [#3-capital-at-risk] Relayers bear risk from: * **Software bugs** — implementation errors in relayer software * **Chain reorganizations** — finality risk where a filled transaction could be reverted * **Settlement delays** — longer-than-expected reimbursement periods App Fees (Integrator Revenue) [#app-fees-integrator-revenue] App fees are an **optional fee you add on top of Across's protocol fees** — your integrator revenue, separate from the LP and relayer fees above. Set `appFee` (a decimal from `0` to `1`, e.g. `0.01` = 1%) and `appFeeRecipient` on your [Swap API](/introduction/swap-api) request. The fee is charged in the output token and paid to `appFeeRecipient` on the destination chain, and appears in the `/swap/approval` fee breakdown. `appFeeRecipient` is required whenever `appFee > 0`, and must be valid **on the destination chain** — an EVM `0x` address for EVM destinations, or a **base58 Solana pubkey for Solana destinations** (now supported). Behavior is otherwise identical across EVM and Solana. Querying Fees [#querying-fees] Use the `/suggested-fees` endpoint to get a full fee breakdown before executing a swap: ```ts title="query-fees.ts" const params = new URLSearchParams({ inputToken: "0xaf88d065e77c8cC2239327C5EDb3A432268e5831", // USDC on Arbitrum outputToken: "0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913", // USDC on Base originChainId: "42161", destinationChainId: "8453", amount: "1000000000", // 1000 USDC }); const res = await fetch( `https://app.across.to/api/suggested-fees?${params}` ); const fees = await res.json(); console.log("Total relay fee:", fees.totalRelayFee.total); console.log("LP fee pct:", fees.lpFee.pct); // 1e16 = 1%, 1e18 = 100% console.log("Relayer capital fee:", fees.relayerCapitalFee.total); console.log("Relayer gas fee:", fees.relayerGasFee.total); console.log("Expected fill time:", fees.expectedFillTimeSec, "seconds"); console.log("Is amount too low?", fees.isAmountTooLow); ``` Fee Response Fields [#fee-response-fields] | Field | Description | | --------------------- | --------------------------------------------------------- | | `totalRelayFee` | Combined LP + relayer fee | | `lpFee` | LP fee component (pct format: 1e16 = 1%) | | `relayerCapitalFee` | Relayer capital opportunity cost | | `relayerGasFee` | Relayer destination gas cost | | `isAmountTooLow` | `true` if the amount is below the minimum for this route | | `expectedFillTimeSec` | Estimated time for a relayer to fill | | `limits` | Min/max deposit amounts for instant and short-delay fills | **Do not cache fee responses.** Fees change with market conditions, pool utilization, and gas prices. Always fetch fresh fees before presenting a quote to users. # Hyperliquid Withdrawals import { Callout } from 'fumadocs-ui/components/callout'; import { Step, Steps } from 'fumadocs-ui/components/steps'; import { Tabs, Tab } from 'fumadocs-ui/components/tabs'; HyperCore is Hyperliquid's margin and matching engine. To move funds off it, the user signs EIP-712 typed signatures that Across submits on-chain. Across handles the HyperCore → HyperEVM lift and delivery to the destination chain. **API key with `swap-gasless` permission required.** [Get an API key + Integrator ID](/tools/integrator-id). Endpoints in order of integration [#endpoints-in-order-of-integration] | Method | Path | Purpose | | ------ | -------------------------------------------------- | ------------------------------------------------- | | `GET` | `/swap/gasless` | Quote — returns the steps the user must sign | | `POST` | `/gasless/submit` | Submit signed steps; relayer takes over from here | | `GET` | `/deposit/status?depositId=...&originChainId=1337` | Track the withdrawal to terminal status | Supported Hyperliquid Origin Tokens [#supported-hyperliquid-origin-tokens] | Symbol | `inputToken` value | Decimals | Balance lives in | | ------------------ | -------------------------------------------- | -------- | ---------------- | | `USDC-spot` | `0x2000000000000000000000000000000000000000` | 8 | HL spot | | `USDC-perps` | `0x2100000000000000000000000000000000000000` | 8 | HL perps margin | | `HYPE` | `0x2222222222222222222222222222222222222222` | 8 | HL spot | | `USDT` (USDT-SPOT) | `0x200000000000000000000000000000000000010C` | 8 | HL spot | The `0x2…` addresses are HyperCore sentinels — they are not HyperEVM ERC-20s. Destinations: any EVM chain Across supports. End-to-end integration flow [#end-to-end-integration-flow] Quote [#quote] ``` GET /swap/gasless ?inputToken=0x2100000000000000000000000000000000000000 # USDC-PERPS &originChainId=1337 # HyperCore &outputToken=0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913 # USDC on Base &destinationChainId=8453 # Base &amount=100000000 # 1 USDC (8 decimals on HC) &depositor= &recipient= &integratorId= ``` **Decimals trap.** `amount` is in the **input token's** decimals. HyperCore tokens use **8 decimals** (HyperEVM and standard EVM USDC use 6) — passing a 6-decimal value for an 8-decimal HyperCore input under-bridges by 100×. Returns `depositId`, the steps to sign in `swapTxns[]`, `quoteExpiryTimestamp`, `expectedOutputAmount`, `minOutputAmount`, and `fees` (the submission fee is at **`fees.submission`** — there is no top-level `submissionFees`). **Submission fee** — the amount (in the input token) paid to the submitter that broadcasts your signed permit on-chain in the gasless flow, reimbursing their gas plus margin. It's part of the signed witness (`submissionFees: { amount, recipient }`), so the user authorizes the exact fee and payee when signing — no separate gas payment from the user. See the [API reference](/api-reference/swap/gasless/get) for the full response shape. Sign every step [#sign-every-step] Iterate `swapTxns` and dispatch by `step.ecosystem`. The user signs **every** step — missing signatures are rejected at submit. Please note that even if a single signature is unsigned or signed incorrectly, the transaction will not go through. ```ts const sigs: Record = {}; for (const step of quote.swapTxns) { if (step.ecosystem === 'hypercore') { sigs[step.stepId] = await hlSign(step.typedData); // HL wallet } else if (step.ecosystem === 'evm-gasless') { sigs[step.stepId] = await evmSign(step.typedData); // EVM EOA — EIP-712 } } ``` **`evm-gasless` chainId gotcha.** Sign at `step.typedData.domain.chainId` (always `999` / HyperEVM), NOT the outer `step.chainId`. If you use a single EVM wallet for both ecosystems, make sure it is on chain `999` before signing every step. Wrong-chain signatures fail server-side `verifyTypedData`. Submit [#submit] ``` POST /gasless/submit { "swapTx": , "swapTxns": , "signaturesByStepId": { "hypercore-transfer": "0x…", "gasless-auth": "0x…" } } ``` Returns `{ depositId, messageId, id }` (`messageId` may be `null`). Submit is gated in two stages: **(1)** every signature must recover to the `depositor` (else `400 "Invalid signature: unable to verify signature"`); **(2)** the integrator key must be eligible for gasless submission (else `403`). It is accepted **optimistically** — a `200` is returned before on-chain execution, so an underfunded withdrawal still returns `200` and later surfaces as `deposit-failed`. See the [API reference](/api-reference/gasless/submit/post) for the full response shape. Track status [#track-status] Poll `/deposit/status` with the `depositId` and `originChainId=1337`: ``` GET /deposit/status?depositId=&originChainId=1337 ``` | Status | Meaning | | ----------------- | --------------------------------------------------------------------------------------------------------- | | `deposit-pending` | HyperCore → HyperEVM lift in progress | | `deposit-failed` | Lift failed (e.g. insufficient HyperCore balance); funds not moved (terminal) | | `filled` | Destination tokens delivered (terminal) | | `expired` | Destination tokens were not delivered within the `fillDeadline` and the user is now eligible for a refund | | `refunded` | Terminal state; user has received a refund | See the [API reference](/api-reference/deposit/status/get) for the full response shape. **Refunds land on HyperEVM, not HyperCore.** `refundToken.chainId` on bridging quotes is `999`. Set `refundOnOrigin: true` and surface the destination in your UI — users won't expect refunds to arrive on HyperEVM. Gas Fees [#gas-fees] HyperCore → HyperEVM mirror moves cost a small HyperEVM gas fee. * **USDC / USDT origin** — fee is paid in-kind or auto-deducted in HYPE. Users don't need to think about it. * **HYPE / non-stablecoin origin** — users must hold HYPE on HyperCore to cover gas. This lift cost is reported at **`fees.submission`** on every quote (a flat amount in the submission token, independent of size). `fees.total` / `fees.totalMax` cover any protocol/relayer spread — `0` for same-asset USDC routes. Minimal Example: HC USDC-PERPS → Base ETH [#minimal-example-hc-usdc-perps--base-eth] ```ts const quote = await fetch(`${BASE}/swap/gasless?inputToken=0x2100…&…`).then(r => r.json()); const sigs: Record = {}; for (const step of quote.swapTxns) { sigs[step.stepId] = step.ecosystem === 'hypercore' ? await hlSign(step.typedData) : await evmSign(step.typedData); } const { depositId } = await fetch(`${BASE}/gasless/submit`, { method: 'POST', body: JSON.stringify({ swapTx: quote.swapTx, swapTxns: quote.swapTxns, signaturesByStepId: sigs, }), }).then(r => r.json()); while (true) { const { status } = await fetch( `${BASE}/deposit/status?depositId=${depositId}&originChainId=1337`, ).then(r => r.json()); if (['filled', 'expired', 'refunded', 'deposit-failed'].includes(status)) break; await new Promise(r => setTimeout(r, 2000)); } ``` Caveats [#caveats] 1. **HL nonces are wallet-unique.** If your client races two quotes, sign + submit them in order — HL will reject a later nonce that arrives first as stale. 2. **Quote expiry is short** (typically 60–120s). After `quoteExpiryTimestamp`, re-quote; submitting a stale quote returns a witness-binding error. 3. **Don't mutate `swapTx` or `swapTxns` between quote and submit.** The submit endpoint re-validates byte-for-byte; any drift returns a deep-equal error. 4. **Trust `fees.submission.amount` from the quote** rather than computing the lift fee yourself. 5. **Very large amounts may exceed a route's available liquidity** and return `400 AMOUNT_TOO_HIGH` (the max is in the message). 6. **`recipient` ≠ `depositor` is fine** — but the `depositor` EOA must own the HC funds and sign every step. All validation errors return `400 InvalidParamError` with a `param` field telling you which input to fix. Most "re-quote" errors are TOCTOU freshness checks — retrying the same body will keep failing. References [#references] * [GET /swap/gasless](/api-reference/swap/gasless/get) — quote endpoint reference * [POST /gasless/submit](/api-reference/gasless/submit/post) — submit endpoint reference * [Working with Hypercore](/introduction/hypercore) — companion deposits guide * [Tracking Deposits](/introduction/tracking-deposits) — generic deposit polling for non-gasless flows * [Refunds](/introduction/refunds) — refund mechanics on Across # Working with Hypercore import { Callout } from 'fumadocs-ui/components/callout'; import { Card, Cards } from 'fumadocs-ui/components/card'; import { Step, Steps } from 'fumadocs-ui/components/steps'; HyperCore is Hyperliquid's high-performance trading layer with sub-second settlement. Across supports bridging assets directly to HyperCore via the Swap API, letting users go from most supported chains to Hyperliquid quickly. **API key required.** [Get your API key and Integrator ID](/tools/integrator-id) to authenticate your requests. Key Parameters [#key-parameters] When bridging to HyperCore, use these specific values: | Parameter | Value | Notes | | -------------------- | ----------------- | ------------------------------- | | `destinationChainId` | `1337` | HyperCore chain ID | | `outputToken` | USDC-SPOT address | The USDC-SPOT token on HyperEVM | HyperCore uses Chain ID **1337**. The Swap API handles the routing from HyperEVM to HyperCore automatically — you don't need to interact with HyperCore directly. How It Works [#how-it-works] Origin Deposit [#origin-deposit] The user deposits assets on the origin chain (e.g., USDT on Arbitrum) via the Swap API. This creates a crosschain intent with HyperEVM as the destination. HyperEVM Fill [#hyperevm-fill] A relayer fills the intent on HyperEVM, delivering the output token (USDC-SPOT) to the recipient address. HyperCore Credit [#hypercore-credit] The bridged funds are automatically credited to the user's HyperCore account. If the user doesn't have a HyperCore account yet, one is initialized automatically. **Automatic account initialization.** If the recipient address doesn't have a HyperCore account, one is created automatically during the bridging process. No manual setup required. Example: Bridge USDT from Arbitrum to HyperCore [#example-bridge-usdt-from-arbitrum-to-hypercore] ```ts title="bridge-to-hypercore.ts" import { createWalletClient, createPublicClient, http, parseUnits } from "viem"; import { arbitrum } from "viem/chains"; import { privateKeyToAccount } from "viem/accounts"; const account = privateKeyToAccount("0xYOUR_PRIVATE_KEY"); const walletClient = createWalletClient({ account, chain: arbitrum, transport: http(), }); const publicClient = createPublicClient({ chain: arbitrum, transport: http(), }); async function bridgeToHyperCore() { const params = new URLSearchParams({ tradeType: "minOutput", originChainId: "42161", // Arbitrum destinationChainId: "1337", // HyperCore inputToken: "0xFd086bC7CD5C481DCC9C85ebE478A1C0b69FCbb9", // USDT on Arbitrum outputToken: "0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913", // USDC-SPOT on HyperEVM amount: parseUnits("500", 6).toString(), // 500 USDT depositor: account.address, integratorId: "0xdead", }); const response = await fetch( `https://app.across.to/api/swap/approval?${params}`, { headers: { Authorization: "Bearer YOUR_API_KEY", }, } ); const quote = await response.json(); if (!quote.swapTx) { throw new Error(`Quote failed: ${JSON.stringify(quote)}`); } console.log("Cross-swap type:", quote.crossSwapType); console.log("Expected fill time:", quote.expectedFillTime, "seconds"); // Execute approvals if (quote.approvalTxns?.length) { for (const approvalTx of quote.approvalTxns) { const hash = await walletClient.sendTransaction({ to: approvalTx.to, data: approvalTx.data, }); await publicClient.waitForTransactionReceipt({ hash }); console.log("Approval confirmed:", hash); } } // Execute the bridge transaction const hash = await walletClient.sendTransaction({ to: quote.swapTx.to, data: quote.swapTx.data, value: quote.swapTx.value ? BigInt(quote.swapTx.value) : 0n, gas: quote.swapTx.gas ? BigInt(quote.swapTx.gas) : undefined, }); console.log("Bridge tx:", hash); // Funds will be credited to HyperCore automatically } bridgeToHyperCore(); ``` Verify the correct USDC-SPOT token address on HyperEVM before production use. Use the `/swap/tokens` endpoint to look up the current address for destination chain `1337`. Withdrawing from HyperCore [#withdrawing-from-hypercore] Going the other direction — moving funds **off** HyperCore to another Across-supported chain — uses a different flow. HyperCore is not EVM-compatible, so users can't broadcast a transaction from there. Instead, they sign **2 EIP-712 payloads** on HyperEVM (chain id `999`) and Across drives the rest: the HyperCore → HyperEVM mirror move, the standard Across gasless deposit on HyperEVM (for non-passthrough routes), and the relayer fill on the destination. The endpoints involved are `GET /swap/gasless` (quote + signing steps) and `POST /gasless/submit` (submit signatures, get a `depositId`). **Users withdrawing HYPE (or non-stablecoin tokens) must hold HYPE on HyperCore to cover HyperCore → HyperEVM gas.** For USDC and USDT, the gas fee can be paid in the token itself or auto-deducted in HYPE — no special action needed. **Refunds for HyperCore withdrawals land on HyperEVM (chain id 999), not HyperCore.** Surface this to users explicitly — they will expect refunds to come back to HyperCore. Learn about HyperCore withdrawals in detail on the next page. # Welcome to Across import { Callout } from 'fumadocs-ui/components/callout'; import { Card, Cards } from 'fumadocs-ui/components/card'; import { Step, Steps } from 'fumadocs-ui/components/steps'; Tempo is now live on Across. Bridge to and from Tempo (Chain ID 4217) using the Swap API. What is Across? [#what-is-across] Across is a **crosschain interoperability protocol** that provides the fastest, cheapest, and most secure way to move assets across blockchains. With \~2 second fills on mainnet and support for 24 chains, Across powers crosschain swaps, bridges, and embedded actions through a single unified API. The [Swap API](/introduction/swap-api) is the single entry point: you request a route and it returns a transaction to execute. Across automatically selects the best settlement path under the hood — you don't need to choose. **API key required for production.** [Get your API key and Integrator ID](/tools/integrator-id) to authenticate your requests. Quick Start [#quick-start] Get a crosschain swap executing in three steps: Get a Quote [#get-a-quote] Call the Swap API with your transfer parameters to get executable calldata. ```ts title="get-quote.ts" const params = new URLSearchParams({ tradeType: "minOutput", originChainId: "42161", // Arbitrum destinationChainId: "8453", // Base inputToken: "0xaf88d065e77c8cC2239327C5EDb3A432268e5831", // USDC on Arbitrum outputToken: "0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913", // USDC on Base amount: "1000000000", // 1000 USDC (6 decimals) depositor: "0xYourWalletAddress", integratorId: "0xdead", // Your integrator ID }); const response = await fetch( `https://app.across.to/api/swap/approval?${params}`, { headers: { Authorization: "Bearer YOUR_API_KEY", }, } ); const quote = await response.json(); ``` See the [`GET /swap/approval` API reference](/api-reference/swap/approval/get) for every parameter and the full response shape. Approve Token Spending [#approve-token-spending] If the quote includes approval transactions, execute them first. ```ts title="approve.ts" import { createWalletClient, http } from "viem"; import { arbitrum } from "viem/chains"; import { privateKeyToAccount } from "viem/accounts"; const account = privateKeyToAccount("0xYOUR_PRIVATE_KEY"); const walletClient = createWalletClient({ account, chain: arbitrum, transport: http(), }); if (quote.approvalTxns?.length) { for (const approvalTx of quote.approvalTxns) { const hash = await walletClient.sendTransaction({ to: approvalTx.to, data: approvalTx.data, }); console.log("Approval tx:", hash); } } ``` Execute the Swap [#execute-the-swap] Send the main swap transaction using the calldata from the quote. ```ts title="execute.ts" const hash = await walletClient.sendTransaction({ to: quote.swapTx.to, data: quote.swapTx.data, value: quote.swapTx.value ? BigInt(quote.swapTx.value) : 0n, gas: quote.swapTx.gas ? BigInt(quote.swapTx.gas) : undefined, }); console.log("Swap tx:", hash); // Funds arrive on Base in ~2 seconds ``` Direct Route Linking [#direct-route-linking] Link users directly to a pre-filled bridge route on the Across UI — no API calls needed. Just construct a URL with query parameters for origin chain, destination chain, and tokens. ``` https://app.across.to/bridge-and-swap?from=8453&to=42161&inputToken=BAL&outputToken=USDC ``` [Learn more about Direct Route Linking to improve your UX →](/guides/user-guides/direct-route-linking) What's Next [#whats-next] Move native USDC and USDT0 across chains with a single Swap API call. Deep dive into the Swap API — parameters, response structure, and integration patterns. Bridge assets to Hyperliquid's sub-second settlement layer. # Persistent Deposit Addresses import { Callout } from 'fumadocs-ui/components/callout'; import { Step, Steps } from 'fumadocs-ui/components/steps'; `POST /deposit-addresses` returns a **persistent, never-expiring** deposit address that delivers a token to a recipient on the destination you specify. The same request parameters always resolve to the **same** address, so you can request it once and reuse it — the **amount is not part of the request**. Send any amount, any time, and it's swept to the destination automatically; no wallet signing or per-transfer quote is required. **API key with the `deposit-address` permission required** (Bearer auth). [Get an API key + Integrator ID](/tools/integrator-id). Supported routes [#supported-routes] Support is **route-specific** — it depends on the origin/destination pair and the tokens on each side, not on the chain alone. There is no single "is this chain supported" flag. | | Chains | | ---------------------------- | --------------------------------------------------------------------------------------------------------------------------------------------------------- | | **Origin** (deposit from) | Ethereum, Optimism, BNB Smart Chain, Polygon, Unichain, Monad, World Chain, HyperEVM, MegaETH, Base, Plasma, Arbitrum, Avalanche, Ink, Linea, Tempo, Tron | | **Destination** (deliver to) | The 17 origin chains above, plus HyperCore (`1337`) | * **Tron** is the only non-EVM chain in the set. Its addresses use the `tron` namespace (base58, `T…`) and arrive as their own entry in `depositInstructions[]` — iterate that array instead of assuming a single EVM address. * **zkSync and Solana are not supported** on either side. **Don't hardcode origins.** The response's `supportedInputs[]` lists every origin chain the address accepts, the token to send on each, that route's min/max limits, and its indicative fees and fill time — read them from there. The list stays current as chains and tokens are added. Unsupported destinations and recipients return `400`. Integrate [#integrate] Request an address [#request-an-address] Send the destination (`token` + `recipient`) and a `refundAddresses` entry to refund to if a deposit can't be completed. The example below requests `USDC-SPOT` on HyperCore; swap in any supported destination token. ```bash curl -X POST https://across.to/api/deposit-addresses \ -H "Authorization: Bearer $ACROSS_API_KEY" \ -H "Content-Type: application/json" \ -d '{ "destination": { "token": { "chainId": 1337, "address": "0x2000000000000000000000000000000000000000" }, "recipient": "0x1111111111111111111111111111111111111111" }, "refundAddresses": [ { "namespace": "evm", "address": "0x2222222222222222222222222222222222222222" } ] }' ``` Read the deposit instruction [#read-the-deposit-instruction] The response returns `depositInstructions[]`. Each has a `depositAddress` (an `Account` — `{ namespace, address }`) and the `supportedInputs` it accepts: origin chain, input token, that route's min/max limits, plus an indicative fee breakdown and fill time. `expiresAt` is always `null`. ```jsonc { "destination": { "token": { "chainId": 1337, "address": "0x2000…0000", "symbol": "USDC-SPOT", "name": "USDC", "decimals": 8 }, "recipient": { "namespace": "evm", "address": "0x1111…1111" } }, "refundAddresses": [ { "namespace": "evm", "address": "0x2222…2222" } ], "expiresAt": null, "depositInstructions": [ { "depositAddress": { "namespace": "evm", "address": "0xAcc0…BD6E" }, "supportedInputs": [ { "originChainId": 1, "inputToken": { "chainId": 1, "address": "0xA0b8…eB48", "symbol": "USDC", "name": "USD Coin", "decimals": 6 }, "limits": { "minInputAmount": "5000000", "maxInputAmount": "10000000000000" }, "indicativeFees": { "proportionalPct": "100000000000000", "fixedFeeUsd": 0.246894 }, "indicativeFillTime": 30 } // …one entry per supported origin chain ] } ], "id": "75795-1781095882239-8e49a5353db9" } ``` Send funds [#send-funds] Send one of the tokens listed in `supportedInputs[]`, on the origin chain that entry names, to the `depositAddress`. It's swept to the destination token and recipient you requested. The address is **amount-agnostic and permanent** — reuse it for future transfers; re-POSTing the same parameters returns the same address. Track your deposit [#track-your-deposit] Two calls: list the deposits made through your deposit address, then fetch full details for the latest one. List deposits for the address [#list-deposits-for-the-address] Call [`GET /deposits`](/api-reference/deposits/get) with the `depositAddress` query param. It returns the transfers sent to that address, newest first, each enriched with the bridge deposit created for it. `depositTxnRef` is the hash of the transfer **you** sent to the deposit address. A transfer that hasn't been swept yet reports status `deposit-pending`; once the sweep is picked up, the item carries the bridge deposit's fill status (`pending` → `filled`). ```bash curl "https://across.to/api/deposits?depositAddress=0xAcc0dDdb8169FD06a34AADd52a39A4166a15BD6E" \ -H "Authorization: Bearer $ACROSS_API_KEY" ``` ```jsonc [ { "status": "filled", "depositTxnRef": "0x92ffc5d69d00e14e79254f68adab030dd38119996501a88cac0da76557703d11" // …other deposit fields } ] ``` Fetch the latest deposit [#fetch-the-latest-deposit] Pick the latest transfer — the first item in the response — and pass its `depositTxnRef` to [`GET /deposit`](/api-reference/deposit/get) for the full deposit record, including fill status. ```bash curl "https://across.to/api/deposit?depositTxnRef=0x92ffc5d69d00e14e79254f68adab030dd38119996501a88cac0da76557703d11" \ -H "Authorization: Bearer $ACROSS_API_KEY" ``` See the full schema, fields, and error responses in the [`POST /deposit-addresses` API reference](/api-reference/deposit-addresses/post). # Refunds import { Callout } from 'fumadocs-ui/components/callout'; import { Step, Steps } from 'fumadocs-ui/components/steps'; Refunds occur when no relayer fills a deposit before its `fillDeadline` expires. This is rare on mainnet — the competitive relayer network fills most deposits in \~2 seconds — but it's important to handle in production integrations. You can check the status of your bridge transaction using our **Status Tracker** tool here: *** When Refunds Happen [#when-refunds-happen] A deposit becomes eligible for a refund when: 1. The `fillDeadline` passes without any relayer filling the intent 2. No partial fills were executed Common causes include extremely large transfers, unusual token pairs, or temporary relayer downtime. Refund Flow [#refund-flow] Deposit Expires [#deposit-expires] The `fillDeadline` passes and the deposit status changes to `expired` in the `/deposit/status` API. The user's funds are still escrowed in the origin SpokePool. Bundle Processing [#bundle-processing] The Across Dataworker includes the expired deposit in the next settlement bundle. Bundles are proposed to the HubPool every \~1.5 hours and must pass a challenge period via UMA's Optimistic Oracle. Settlement [#settlement] After the challenge period, the bundle is finalized and the refund root is transmitted to the appropriate chain via canonical bridges. Refund Execution [#refund-execution] The refund is executed on-chain, returning the escrowed funds to the `refundAddress`. The deposit status changes to `refunded` in the API. **Refunds are not instant.** After a deposit expires, the refund goes through the bundle settlement process. With \~1.5-hour bundle intervals plus the challenge period and canonical bridge delays, refunds can take **several hours** to arrive. Do not tell users to expect immediate refunds. Refund Parameters [#refund-parameters] Configure refund behavior when calling the Swap API. | Parameter | Type | Default | Description | | ---------------- | --------- | ----------- | -------------------------------------------------------------------------- | | `refundAddress` | `string` | `depositor` | Address that receives the refund | | `refundOnOrigin` | `boolean` | `true` | If `true`, refund on origin chain. If `false`, refund on destination chain | ```ts title="swap-with-refund-config.ts" const params = new URLSearchParams({ tradeType: "minOutput", originChainId: "42161", destinationChainId: "8453", inputToken: "0xaf88d065e77c8cC2239327C5EDb3A432268e5831", outputToken: "0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913", amount: "1000000000", depositor: "0xYourWalletAddress", // Refund configuration refundAddress: "0xYourWalletAddress", // Where to send the refund refundOnOrigin: "true", // Refund on Arbitrum (origin) }); const response = await fetch( `https://app.across.to/api/swap/approval?${params}` ); ``` Checking Refund Status [#checking-refund-status] Use the `/deposit/status` endpoint to monitor whether an expired deposit has been refunded. ```ts title="check-refund.ts" import { createPublicClient, http } from "viem"; import { arbitrum } from "viem/chains"; const BASE_URL = "https://app.across.to/api"; async function checkRefundStatus(originChainId: number, depositId: number) { const params = new URLSearchParams({ originChainId: originChainId.toString(), depositId: depositId.toString(), }); const res = await fetch(`${BASE_URL}/deposit/status?${params}`); const data = await res.json(); switch (data.status) { case "pending": console.log("Deposit still pending — waiting for fill"); break; case "filled": console.log("Deposit filled successfully — no refund needed"); break; case "expired": console.log("Deposit expired — refund is being processed"); console.log("Refund will arrive after bundle settlement (~hours)"); break; case "refunded": console.log("Refund complete — funds returned to refund address"); break; } return data.status; } // Poll until refunded async function waitForRefund(originChainId: number, depositId: number) { const intervalMs = 60_000; // Check every minute for refunds const maxAttempts = 360; // Up to 6 hours for (let i = 0; i < maxAttempts; i++) { const status = await checkRefundStatus(originChainId, depositId); if (status === "refunded") { return "refunded"; } if (status === "filled") { return "filled"; // Was filled after all — no refund needed } await new Promise((resolve) => setTimeout(resolve, intervalMs)); } throw new Error("Refund polling timed out"); } ``` For refund polling, use a **60-second interval** instead of the 10-second interval used for fill tracking. Refunds take hours, not seconds, so frequent polling is unnecessary. # Across for Stablecoins import { Callout } from 'fumadocs-ui/components/callout'; import { Tabs, Tab } from 'fumadocs-ui/components/tabs'; Across moves native stablecoins across every supported chain through one [Swap API](/introduction/swap-api) call — no wrapped tokens. You request a route; Across picks the best settlement path automatically and returns a transaction to execute. **API key required for production.** [Get your API key and Integrator ID](/tools/integrator-id) to authenticate your requests. Sponsored Routes [#sponsored-routes] Select stablecoin routes have zero bridge fees, subsidized by the protocol. **Currently sponsored:** * **USDT / USDT0 → USDC-SPOT, USDC-PERPS** on HyperCore from Ethereum, Arbitrum, Monad, Polygon, Unichain Sponsored routes change over time. To check if a route is currently sponsored, inspect the `fees` object in the `/swap/approval` response. Stablecoin Contract Addresses [#stablecoin-contract-addresses] **Always verify addresses** via the [`/swap/tokens`](/api-reference/swap/tokens/get) endpoint. Token addresses can change as new deployments roll out. | Chain | Address | | -------- | -------------------------------------------- | | Ethereum | `0xA0b86991c6218b36c1d19D4a2e9Eb0cE3606eB48` | | Arbitrum | `0xaf88d065e77c8cC2239327C5EDb3A432268e5831` | | Base | `0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913` | | Optimism | `0x0b2C639c533813f4Aa9D7837CAf62653d097Ff85` | | Polygon | `0x3c499c542cEF5E3811e1192ce70d8cC03d5c3359` | Use [`/swap/tokens?chainId=`](/api-reference/swap/tokens/get) for the complete list across all supported chains. | Chain | Address | | -------- | -------------------------------------------- | | Ethereum | `0xdAC17F958D2ee523a2206206994597C13D831ec7` | | Arbitrum | `0xFd086bC7CD5C481DCC9C85ebE478A1C0b69FCbb9` | | Optimism | `0x94b008aA00579c1307B0EF2c499aD98a8ce58e58` | Use `/swap/tokens?chainId=` for the complete list. This is a subset of supported chains. Query `/swap/tokens` for the full matrix of stablecoins and chains. Example: Large USDC Transfer [#example-large-usdc-transfer] One `/swap/approval` call quotes the route and returns the transaction(s) to execute. The integration code is the same for every stablecoin route, regardless of size. ```ts title="usdc-transfer.ts" import { createWalletClient, createPublicClient, http } from "viem"; import { mainnet } from "viem/chains"; import { privateKeyToAccount } from "viem/accounts"; const account = privateKeyToAccount("0xYOUR_PRIVATE_KEY"); const walletClient = createWalletClient({ account, chain: mainnet, transport: http() }); const publicClient = createPublicClient({ chain: mainnet, transport: http() }); const params = new URLSearchParams({ tradeType: "minOutput", originChainId: "1", destinationChainId: "42161", inputToken: "0xA0b86991c6218b36c1d19D4a2e9Eb0cE3606eB48", // USDC on Ethereum outputToken: "0xaf88d065e77c8cC2239327C5EDb3A432268e5831", // USDC on Arbitrum amount: "1000000000", // 1,000 USDC (6 decimals) depositor: account.address, }); const quote = await fetch( `https://app.across.to/api/swap/approval?${params}`, { headers: { Authorization: "Bearer YOUR_API_KEY" } }, ).then((r) => r.json()); // Execute approvals (if any), then the swap if (quote.approvalTxns?.length) { for (const approvalTx of quote.approvalTxns) { const hash = await walletClient.sendTransaction({ to: approvalTx.to, data: approvalTx.data }); await publicClient.waitForTransactionReceipt({ hash }); } } const hash = await walletClient.sendTransaction({ to: quote.swapTx.to, data: quote.swapTx.data, value: quote.swapTx.value ? BigInt(quote.swapTx.value) : 0n, }); console.log("Transfer tx:", hash); ``` See the [`GET /swap/approval` API reference](/api-reference/swap/approval/get) for every parameter and the full response shape. The integration code is identical for every stablecoin route — call `/swap/approval`, execute any approvals, then send the returned transaction. Across handles settlement behind the scenes. # Introduction to Swap API import { Callout } from 'fumadocs-ui/components/callout'; import { Card, Cards } from 'fumadocs-ui/components/card'; import { Tabs, Tab } from 'fumadocs-ui/components/tabs'; The Swap API is Across's **single entry point** for all crosschain operations — bridging, swapping, and embedded actions. One unified interface at `/swap/approval` quotes any route; Across selects the best settlement path automatically, so your integration stays the same regardless of token, amount, or chain. **API key required for production.** [Get your API key and Integrator ID](/tools/integrator-id) to authenticate your requests. Trade Types [#trade-types] The `tradeType` parameter controls how the swap amount is interpreted. **Spend exactly this amount, receive whatever the market gives.** Use when the user specifies how much they want to send. The output amount varies based on fees, slippage, and exchange rates. ``` tradeType=exactInput&amount=1000000000 ``` **Receive at least this amount, spend whatever is needed.** Use when the user has a minimum acceptable output. The API calculates the required input. This is the recommended default for most integrations. ``` tradeType=minOutput&amount=1000000000 ``` **Receive exactly this amount.** Use when the user needs a precise output. Stricter than `minOutput` — the API will fail if the exact amount can't be delivered. Set `strictTradeType=true` to enforce. ``` tradeType=exactOutput&amount=1000000000&strictTradeType=true ``` Base URLs [#base-urls] | Environment | Base URL | | ----------- | --------------------------- | | Production | `https://app.across.to/api` | Required Parameters [#required-parameters] | Parameter | Type | Description | | -------------------- | -------- | -------------------------------------------------- | | `tradeType` | `string` | `exactInput`, `minOutput`, or `exactOutput` | | `amount` | `string` | Amount in smallest unit (e.g., `1000000` = 1 USDC) | | `inputToken` | `string` | Token address on origin chain | | `outputToken` | `string` | Token address on destination chain | | `originChainId` | `number` | Origin chain ID | | `destinationChainId` | `number` | Destination chain ID | | `depositor` | `string` | Wallet address initiating the transfer | Optional Parameters [#optional-parameters] | Parameter | Type | Description | | ------------------------ | --------- | --------------------------------------------------------------------------------------------------------------------------------------------------------- | | `recipient` | `string` | Destination address (defaults to `depositor`) | | `integratorId` | `string` | 2-byte hex identifier for your integration | | `slippage` | `string` | `"auto"` or a value between 0-1 (default: auto) | | `refundAddress` | `string` | Address for refunds if fill expires | | `refundOnOrigin` | `boolean` | Refund on origin chain instead of destination | | `appFee` | `string` | Integrator fee as decimal 0-1 (e.g., `"0.01"` = 1%). Charged in the output token on the destination chain | | `appFeeRecipient` | `string` | Address that receives the app fee, on the **destination chain** — EVM hex, or a base58 Solana pubkey for Solana destinations. Required if `appFee` is set | | `skipOriginTxEstimation` | `boolean` | Skip gas estimation for the origin transaction | | `strictTradeType` | `boolean` | Fail if exact trade type can't be satisfied | | `excludeSources` | `string` | Comma-separated swap sources to exclude | | `includeSources` | `string` | Comma-separated swap sources to include exclusively | See the [`GET /swap/approval` API reference](/api-reference/swap/approval/get) for the complete, always-current parameter list and response schema. Response Structure [#response-structure] The `/swap/approval` response contains everything needed to execute the crosschain transfer. ```json title="response-structure.json" { "crossSwapType": "bridgeableToBridgeable", "checks": { "allowance": { "token": "0x...", "spender": "0x...", "actual": "0", "expected": "1000000" }, "balance": { "token": "0x...", "actual": "5000000", "expected": "1000000" } }, "approvalTxns": [ { "chainId": 42161, "to": "0x...", "data": "0x..." } ], "steps": { "bridge": { "inputAmount": "1000000", "outputAmount": "998000" } }, "fees": { "total": "2000", "totalMax": "3000", "originGas": "50000" }, "swapTx": { "simulationSuccess": true, "chainId": 42161, "to": "0x...", "data": "0x...", "value": "0", "gas": "250000", "maxFeePerGas": "100000000", "maxPriorityFeePerGas": "1500000" }, "expectedFillTime": 2, "quoteExpiryTimestamp": 1700000000 } ``` **Key fields:** * **`crossSwapType`** — The routing path: `bridgeableToBridgeable`, `bridgeableToBridgeableIndirect`, `bridgeableToAny`, `anyToBridgeable`, or `anyToAny` * **`checks`** — Current allowance and balance status for the depositor * **`approvalTxns`** — Token approval transactions to execute before the swap (may be empty) * **`swapTx`** — The main swap transaction calldata * **`expectedFillTime`** — Estimated seconds until the destination fill * **`quoteExpiryTimestamp`** — Unix timestamp when this quote expires Full Integration Example [#full-integration-example] ```ts title="swap-viem.ts" import { createWalletClient, createPublicClient, http, parseUnits } from "viem"; import { arbitrum } from "viem/chains"; import { privateKeyToAccount } from "viem/accounts"; const account = privateKeyToAccount("0xYOUR_PRIVATE_KEY"); const walletClient = createWalletClient({ account, chain: arbitrum, transport: http(), }); const publicClient = createPublicClient({ chain: arbitrum, transport: http(), }); async function executeSwap() { // 1. Get quote const params = new URLSearchParams({ tradeType: "minOutput", originChainId: "42161", destinationChainId: "8453", inputToken: "0xaf88d065e77c8cC2239327C5EDb3A432268e5831", // USDC on Arbitrum outputToken: "0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913", // USDC on Base amount: parseUnits("100", 6).toString(), // 100 USDC depositor: account.address, integratorId: "0xdead", }); const res = await fetch( `https://app.across.to/api/swap/approval?${params}`, { headers: { Authorization: "Bearer YOUR_API_KEY", }, } ); const quote = await res.json(); if (!quote.swapTx) { throw new Error(`Quote failed: ${JSON.stringify(quote)}`); } // 2. Execute approval transactions if (quote.approvalTxns?.length) { for (const approvalTx of quote.approvalTxns) { const hash = await walletClient.sendTransaction({ to: approvalTx.to, data: approvalTx.data, }); await publicClient.waitForTransactionReceipt({ hash }); console.log("Approval confirmed:", hash); } } // 3. Execute swap const hash = await walletClient.sendTransaction({ to: quote.swapTx.to, data: quote.swapTx.data, value: quote.swapTx.value ? BigInt(quote.swapTx.value) : 0n, gas: quote.swapTx.gas ? BigInt(quote.swapTx.gas) : undefined, }); console.log("Swap tx:", hash); console.log("Expected fill:", quote.expectedFillTime, "seconds"); return hash; } executeSwap(); ``` ```ts title="swap-ethers.ts" import { ethers } from "ethers"; const provider = new ethers.JsonRpcProvider("https://arb1.arbitrum.io/rpc"); const wallet = new ethers.Wallet("0xYOUR_PRIVATE_KEY", provider); async function executeSwap() { // 1. Get quote const params = new URLSearchParams({ tradeType: "minOutput", originChainId: "42161", destinationChainId: "8453", inputToken: "0xaf88d065e77c8cC2239327C5EDb3A432268e5831", outputToken: "0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913", amount: ethers.parseUnits("100", 6).toString(), depositor: wallet.address, integratorId: "0xdead", }); const res = await fetch( `https://app.across.to/api/swap/approval?${params}`, { headers: { Authorization: "Bearer YOUR_API_KEY", }, } ); const quote = await res.json(); if (!quote.swapTx) { throw new Error(`Quote failed: ${JSON.stringify(quote)}`); } // 2. Execute approval transactions if (quote.approvalTxns?.length) { for (const approvalTx of quote.approvalTxns) { const tx = await wallet.sendTransaction({ to: approvalTx.to, data: approvalTx.data, }); await tx.wait(); console.log("Approval confirmed:", tx.hash); } } // 3. Execute swap const tx = await wallet.sendTransaction({ to: quote.swapTx.to, data: quote.swapTx.data, value: quote.swapTx.value || 0, }); console.log("Swap tx:", tx.hash); console.log("Expected fill:", quote.expectedFillTime, "seconds"); return tx.hash; } executeSwap(); ``` **Integrator ID required for production.** You must obtain a 2-byte hex integrator ID (e.g., `0xdead`) before launching in production. [Get your API key and Integrator ID](/tools/integrator-id). Without it, your requests may be rate-limited or rejected. Helper Endpoints [#helper-endpoints] These endpoints help you discover supported routes, tokens, and fee estimates before calling `/swap/approval`. | Endpoint | Method | Description | | ------------------- | ------ | ---------------------------------------------------- | | `/swap/chains` | GET | List all supported chains | | `/swap/tokens` | GET | List all supported tokens per chain | | `/swap/sources` | GET | List swap providers (DEX sources) | | `/suggested-fees` | GET | *(legacy)* Get fee breakdown for a specific route | | `/limits` | GET | Get transfer limits (min, max, instant, short-delay) | | `/available-routes` | GET | Get all available origin → destination routes | Coming from `/suggested-fees` + direct `depositV3`? See [Migrate from Suggested Fees to the Swap API](/guides/migration/suggested-fees-to-swap). **Integrator ID required for production.** You must obtain a 2-byte hex integrator ID (e.g., `0xdead`) before launching in production. [Get your API key and Integrator ID](/tools/integrator-id). Without it, your requests may be rate-limited or rejected. **Do not cache** `/swap/approval` or `/suggested-fees` responses. Quotes expire quickly and fees change with market conditions. The only stateful endpoint is `/deposit/status`. # Tracking Deposits import { Callout } from 'fumadocs-ui/components/callout'; import { Tabs, Tab } from 'fumadocs-ui/components/tabs'; **API key required for production.** [Get your API key and Integrator ID](/tools/integrator-id) to authenticate your requests. After executing a swap transaction, use the `/deposit/status` endpoint to track whether the deposit has been filled, is still pending, or has expired. Status Values [#status-values] | Status | Description | | ---------- | --------------------------------------------------------- | | `pending` | Deposit submitted but not yet filled by a relayer | | `filled` | Relayer has filled the intent on the destination chain | | `expired` | Fill deadline passed without a fill (eligible for refund) | | `refunded` | Deposit was refunded after expiration | During the pre-fill window (while `status` is `pending` or `received`), the response also returns `originToken` and `destinationToken` — the token addresses taken from the deposit witness. Both are `null` once the deposit is filled. Query Methods [#query-methods] You can query deposit status in two ways: by `depositId` (extracted from the deposit event) or by the deposit transaction hash. Query with the `originChainId` and `depositId` from the `V3FundsDeposited` event. ``` GET /deposit/status?originChainId=42161&depositId=12345 ``` Query with the deposit transaction hash. The API will look up the deposit event from the transaction. ``` GET /deposit/status?depositTxnRef=0xabc123... ``` Extracting the Deposit ID [#extracting-the-deposit-id] When you submit a swap transaction, the origin SpokePool emits a `V3FundsDeposited` event. Extract the `depositId` from this event to use for status tracking. ```ts title="extract-deposit-id.ts" import { createPublicClient, http, parseAbiItem } from "viem"; import { arbitrum } from "viem/chains"; const publicClient = createPublicClient({ chain: arbitrum, transport: http(), }); const SPOKE_POOL_ADDRESS = "0xe35e9842fceaca96570b734083f4a58e8f7c5f2a"; async function getDepositId(txHash: `0x${string}`) { const receipt = await publicClient.getTransactionReceipt({ hash: txHash }); const depositEvent = parseAbiItem( "event V3FundsDeposited(address inputToken, address outputToken, uint256 inputAmount, uint256 outputAmount, uint256 indexed destinationChainId, uint32 indexed depositId, uint32 quoteTimestamp, uint32 fillDeadline, uint32 exclusivityDeadline, address indexed depositor, address recipient, address exclusiveRelayer, bytes message)" ); const logs = await publicClient.getLogs({ address: SPOKE_POOL_ADDRESS, event: depositEvent, fromBlock: receipt.blockNumber, toBlock: receipt.blockNumber, }); if (logs.length === 0) { throw new Error("No V3FundsDeposited event found in transaction"); } const depositId = logs[0].args.depositId; console.log("Deposit ID:", depositId); return depositId; } ``` Polling for Status [#polling-for-status] Poll the `/deposit/status` endpoint until the deposit reaches a terminal state (`filled`, `expired`, or `refunded`). ```ts title="poll-status.ts" const BASE_URL = "https://app.across.to/api"; async function pollDepositStatus( originChainId: number, depositId: number, intervalMs = 10_000, maxAttempts = 60 ): Promise { for (let i = 0; i < maxAttempts; i++) { const params = new URLSearchParams({ originChainId: originChainId.toString(), depositId: depositId.toString(), }); const res = await fetch(`${BASE_URL}/deposit/status?${params}`); const data = await res.json(); console.log(`[Attempt ${i + 1}] Status: ${data.status}`); if (data.status === "filled") { console.log("Deposit filled on destination chain"); return data.status; } if (data.status === "expired") { console.log("Deposit expired — eligible for refund"); return data.status; } if (data.status === "refunded") { console.log("Deposit refunded"); return data.status; } // Wait before next poll await new Promise((resolve) => setTimeout(resolve, intervalMs)); } throw new Error("Polling timed out"); } // Usage const status = await pollDepositStatus(42161, 12345); ``` Polling Recommendations [#polling-recommendations] **10-second polling interval.** The Across indexer has a latency of 1-15 seconds. Polling more frequently than every 10 seconds won't return faster results and will waste API calls. * **Mainnet fills** typically complete in \~2 seconds, but the indexer may take 1-15 seconds to reflect the status * **Testnet fills** take \~1 minute * Set a reasonable timeout (e.g., 10 minutes) to avoid polling indefinitely * For production integrations, consider using a webhook or event-based approach alongside polling Alternative: Query by Transaction Hash [#alternative-query-by-transaction-hash] If you don't want to extract the `depositId`, you can query directly with the transaction hash: ```ts title="poll-by-hash.ts" async function pollByTxHash( txHash: string, intervalMs = 10_000, maxAttempts = 60 ): Promise { for (let i = 0; i < maxAttempts; i++) { const params = new URLSearchParams({ depositTxnRef: txHash }); const res = await fetch(`${BASE_URL}/deposit/status?${params}`); const data = await res.json(); console.log(`[Attempt ${i + 1}] Status: ${data.status}`); if (["filled", "expired", "refunded"].includes(data.status)) { return data.status; } await new Promise((resolve) => setTimeout(resolve, intervalMs)); } throw new Error("Polling timed out"); } ``` # Why Across import { Card, Cards } from 'fumadocs-ui/components/card'; Integration Simplicity [#integration-simplicity] One API call bridges or swaps across any supported chain. `GET /swap/approval` returns ready-to-execute calldata — Across handles routing, settlement, and gas under the hood, so your integration stays the same for every token, amount, and route. Speed [#speed] Across delivers **sub-2-second fills** on mainnet — funds reach the recipient on the destination chain almost immediately, with no waiting on slow finality. The fastest way to feel it is to move something. Cost [#cost] Across is one of the cheapest ways to move assets crosschain: * **Market-based pricing** — every transfer is quoted competitively per route, not charged a flat bridge toll, so you get the lowest sustainable rate. * **Transparent, all-in fees** — each quote returns an explicit `fees` breakdown, so the total cost is known before you submit. No hidden spread, no surprise surcharges. * **Efficient infrastructure** — low operating overhead is passed through to the fee you see, not tacked on top. Security [#security] Across's security model combines: * **Optimistic verification** with UMA's Optimistic Oracle — bundles are accepted unless challenged * **Economic bonds** — proposers stake capital that can be slashed for invalid bundles * **Only one honest actor needed** — a single honest dispute is enough to reject a bad bundle * **V4 ZK proofs** — Succinct/SP1 zero-knowledge proofs provide cryptographic settlement verification Chain Coverage [#chain-coverage] **23+ mainnet chains** and **8 testnet chains**, including first-mover support for Solana, MegaETH, Plasma, Monad, and Hyperliquid. Check whether a specific chain or token is supported:
